New Usb Logic Analyzer Device Cable Set 8ch 24m 24mhz Test For Arm Fpga

C $11.49

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

Description Payment Shipping Return Policy About Us SHOP CATEGORIES Agriculture Tools Metalworking Containers Equipment Manufacturing Packing Other Description This logic analyser contains generic Cypress CY7C68013A microcontroller based hardware.It is re-programmable so that quite flexible in what you can do with it. By default its USB interface is programmed with a VID (Vendor ID) & PID (Product ID) identification which makes it appear as a logic analyser and therefore will work with this software out of the box. However the VID & PID can be changed to anything you want which can allow it to work with other software such as USB. Specification: Sampling rate up to: 24 MHz , can be 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; The logic for each channel sampling rate of 24M/s. General applications around 10M, enough to cope with a variety ofoccasions; 8-channel; Voltage range: Input voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input High Voltage: 2.0V to 5.25V Works with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended. Input Impedance: 1Mohm || 10pF (typical, approximate) Crystal: +/-20ppm, 24MHz Error/Accuracy: pulse-width measurement: +/- 42ns (at 24MHz). Package included: 1 x Analyser Device 1 x USB Cable 10 x Dupont Line Payment Paypal only: Paypal allows you to pay by credit card, debit cards, bank transfers and Paypal account balances. For more information, Please check at www.paypal.com. Shipping 1. We ship your orders within 1-2 business days after the payment cleared. 2. In most times item will reach most of the countries within 8 to 15 working days. To some remote areas may take more than 20 working days. 3. Delivery time depends on destination and other factors, it may takes up to 20 working days. If you don't receive the item after 30 days, please contact us, we'll investigate and solve the delivery problem. To some remote areas may take more than 45 days! 4. Combine Shipping: We do not offer Combine Shipping Service. You need full amount of each shipping fee and insurance. Warranty and Return 1. One year warranty. Buy with confidence! 2. If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact us before you return it. 3. All items come with 3 Months' Basic Sellers Warranty. If item is defective in 3 Months, We will offer replacement withour extra charger(including shipping fee) after we receive the defective item. 4. If item is defective after 3 month, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. If item DOA(Dead of Arrival), buyers can return it in 14 Days, we will replace it with a new item after we receive the DOA item. Please contact us bafore you send the item back. About Us 1. If you are in any way dissatisfied with your purchase, let us know through "MY MESSAGES" or "Ask Seller Q" or our mailbox. We will solve it for you. We are committed to ensuring that you are completely satisfied with every transaction. 100% satisfaction guaranteed! 2. We will reply your mail within 24 hours normally. Sometimes it may have a little delay due to weekends or holidays. If you can't get our mail within 48 hours, please check your drafts or contact us via ebay. Feedback Please give us Five Star Rating! Thank you very much! Related Items
