Hydrographics Hydro Dip Tank Rinse Station Shop Special - 6ft Stainless Steel

US $8,499.00

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

855-900-3477 This is the perfect tank for a small business looking to grow their hydrographics business! MADE IN THE USA | 5 YEAR WARRANTY DIP TANK SPECS 6FT STAINLESS STEEL DIP TANK SPECIFICATIONS: Tank Specifications: •The tank is 14GA 304 STAINLESS STEEL (2B FINISH) with Frame and 4 Heavy Duty Casters •Standard Equipment Dimensions: 72"L x 42"W x 34"D - 445 Gallon Capacity (You can dip larger items such as: ATV plastics, golf cart bodies, bumpers, side steps, RTV plastics, dashboards, etc.) •The STAINLESS STEEL Film Guides sit on the lip of the tank. The film guides are used to adjust a custom size dipping grid in order to hold your film in place when applying the activator. We supply (2) Vertical notched guides and (1) Horizontal guide. You can slide the vertical guides from left to right to adjust grid width, and you can place the horizontal guide in various notched positions to adjust grid height. •The tank sits on a Heavy Duty Reinforced - Powder Coated Steel Angle Frame with center gussets. The frame has 4 Heavy Duty Swivel Casters. The casters are bolted on to Extended Heavy Duty Stainless Steel Plates. This design allows you to roll the tank around in order to place and move it where needed. •The top lip perimeter of the tank is reinforced with a UniStrut frame so that the tank will not bow out or deflect when filled with all the volume of water. Control Panel Specifications: •NEMA Enclosure Control Panel (Gray Powder Coated Finish) •Standard Control Panel Dimensions: 14.25"H x 10.25"W •Standard Electrical Specifications: 220V / Single Phase / 40 Amps •Standard Control Panel design is mounted on the right hand side of the tank and angled at 45 degrees (facing the operator). The panel is mounted on a powder coated square tube post and is bolted on to a 304 Stainless Steel Mounting Plate where the pump sits. This mounting plate design allows easy access to the pump, fittings, hoses, and all other plumbing for ease of cleaning or maintenance. •The Standard Panel comes equipped with: Dial Temperature Controller, Dial Countdown Timer with Buzzer (90dB), Power Disconnect Switch (Mounted on Right Side of Panel), (3) Indicator Lights (Red Light for Main Power On/Off • Green Light for Heater On/Off • Green Light for Filtration Pump On/Off), (3) On/Off Selector Switches For - Heater, Filtration Pump, & Timer. •Panel will come with 6FT of SO Cord. Cord has 4 wires (2 Hot Lines, 1 Neutral Line, 1 Ground). You can hard wire the panel to your junction box or install a 4-Prong 220V Plug. (Be sure to comply with your local electrical code regulations.) •We can also install the panel on the left side for custom applications. We can powder coat or apply a hydrographics finish to your panel in any color or pattern you select. We can also install your selelction of any type of digital controls, LED lights, indicators, switches, etc. Heating System Specifications: •This Tank comes equipped with (1) 304 Stainless Steel Bayonet Heater. The heater is corner-flange mounted for ease of removal for maintenance and cleaning. These standard heaters are 240V, Single Phase, 3K Watts, Alkaline Resistant, Continuous Duty. The heaters are wired to a 304 Stainless Steel Thermocouple, which detects water temperature and is directly wired to the temperature controller on the control panel. The heaters will cycle on & off, sustaining your water temperature at the target temperature setting on the panel. •We can also install any type of heaters for any custom applications. We can install these styles and configurations of heaters: "Screw Plug" / Sidewall Mounted, "Bayonet" / Corner-Flange Mounted. We can also install heaters with any particular wattage and voltage specifications. Filtration System Specifications: •This Tank comes equipped with a 2-Stage "Spray Bar Style" Filtration System. The Standard Spray Bar is constructed from 304 Stainless Steel Pipe with pressure flow controlled jets. It is mounted on the inside of the tank with a u-bolt design. This way you can easily adjust the height of the spray bar. After you dip an item, the operator turns on the selector switch for the pump. This will activate the filtration system and spray high pressure water from the spray bar jets to skim your contaminated water over to the opposite end of the tank. That water will cascade into the filter housing, pass through the media filter, and trap any excess film particles. This will clear your dip area of any residual film or activator within 1 minute. The filtered water will then flow back to your pump through the return line, and pass through the 2nd Stage Y-Strainer filter that has a fine mesh 80 micron re-usable filter. And then the completely filtered water will pass back through the spray bar assembly. The Filter Housing is constructed out of 14GA 304 Stainless Steel. It has a Flange Mounted design with fasteners for easy removal for cleaning; and also to utilize the additional space in the tank if needed. The media filter is an aluminum-foam mesh particle filter that is re-usable. To clean, you simply pry it out, backflow rinse wash, and place it back into the frame in the filter housing. •We can also install the spray bar externally for custom applications. With this design, the spray bar is fixed-mounted to the outside sidewall of the tank. We then install the swivel brass jets on the inside sidewall of the tank. Equipment Pumps Specifications: •Heavy Duty Centrifugal Filtration Pump is 220V, 1HP, Extended Life, Seal Less, Stainless Heads, 3400 RPM Motor, 1" Inlet x 1" Outlet. •We can also install any type of pump for custom applications (HP, GPM, Inlet/Outlet Dimensions, Voltage, RPM, etc.) RINSE STATION SPECS 6FT DIP TANK SPECIFICATIONS: Polyethylene Chemical / Impact Resistant Tank - 72?L X 43?W X 38?H Frame: Heavy Duty Wrinkle Black Powdercoat 4 Heavy Duty Swivel Casters Parts Table: HD Plastic Shelf Grading Rinse System: 6 Adjustable Sprayers Stainless Lines Ball Valve Pressure Flow Control Manual Hose Spray Ball Valve Drain We also provide dip tips and techniques after purchase by calling us toll free at 855-900-3477 BUY IT NOW and start hydro dipping for yourself, your friends, family, and future clients!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Stainless Steel
Country/Region of Manufacture	United States
Model	Dip Tank Rinse Station
