Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: JDSU HST-3000 SIM E1 Module (BC# 24692) JDSU P/N: 80-42047-01 Cable BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! JDSU HST-3000 SIM E1 Module Intended to be used to commission and maintain E1 circuits For Use With HST-3000 & HST-3000C Mainframes (HST-3000 & HST-3000C Mainframe Not Included In Sale!) Working Condition: Excellent Condition: Refurbished Warranty: 90 Day Exchange Warranty JDSU HST-3000 E1 SIM Module Dual E1RX/TX Two separate receivers (RX) and transmitters (TX) allow for the simultaneous monitoring and evaluation of a wide range of alarms and errors. Different test modes with clock preferences support all of the requirements for ITU-T G.703 frame analysis, BERT, ITU-T G.821, ITU-T G.826, and ITU-T M.2100. This enables operators to validate connectivity and QoS quickly and efficiently. E1 Pulse Shape Option Incorrect pulse shape, due to jitter or incorrectly terminated interfaces, causes poor network performance. The Pulse Shape software option quickly assists in identifying network problems during installation, commissioning, or troubleshooting by comparing the pulsewith the ITU-T G.703 pulse mask.The software averages the received E1 pulse and automatically displays the result against the ITU-T mask. FrameRelay Option With the Frame Relay software option, technicians can verify that frame relay service is functioning properly by testing LMI activity, PVC/DLCI status, congestion, and lost framesto validate committed information rates(CIR). Bidirectional Monitoring The HST-3000 can monitor transmission passively in both directions to confirm physical layer and service level results on E1 Circuits. Specifications: Transmitters To G.703 Outputs 2x balanced RJ-48 jacks Impedance 120ohms Unbalanced / 75ohms via adapter cables Bit Rate 2048 kbit/s , +/- 3 ppm, +1 ppm per year aging Line Code HDB3 or AMI Frequency Offset +/- 100ppm in 1ppm intervals Slip Reference Opposite RX, External E1 Reference Clock Clock Source Internal, Recovered from RX1 or RX2, External E1 Reference Clock (via optional cable) Receivers To G.703 Inputs 2x balanced RJ-48 jacks Impedance 120ohms or bridged (hi-Z) Unbalanced / 75ohms via adapter cables PMP Compensation 20 to 31dB gain Bit Rate 2048 kbit/s Level Measurement +3 to -37dB nom Slip Reference Opposite RX, External E1 Reference Clock External E1 Reference Clock 0.5 to 3V square or sine wave, 2,048MHz, unbalanced / 75ohms (at adapter cable input) E1 Circuit Testing Framed and unframed test signal generation Bulk, n x64kbit/s BERT G.821, G.826, M.2100 analysis Error and alarm and generation and analysis Round Trip Delay Signal Level and Frequency Audio Monitor Si, Sa, A-bit, and E-Bit (REBE) monitoring and generation Test Modes Terminate, Monitor, Drop and Insert, Line Loopback Performance Measurement G.821, G.826, M.2100 Test Patterns 2^6-1 (ITU), 2^9-1 (ITU), 2^11-1 (ITU), 2^15-1 (ITU & ITU INV), 2^20-1(ITU & ITU INV), 2^23-1 (ITU & ITU INV), QRSS, QBF Mark (All Ones), Space (All Zeros), 1:1, 1:3, 1:4, 1:7 User Bit Patterns 3 to 32 bits User Byte Patterns 1 to 64 bytes Live Delay Auto (via Auto Configure) Anomaly (Error) Injection Bit (TSE) Single, rate, multiple Code, CRC, Pattern Slip, E-Bit (REBE) Simple FAS Single, 2, 3, 4 MFAS Single, 2 Defect (Alarm) Generation LOS, LOF, AIS, RDI/FAS distant, MF AIS (TS-16), MF RDI/MFAS distant Anomaly (Errors) Counts Bit(TSE), Code, FAS, MFAS, CRC, E-Bit Frame Data Sa4, Sa5, Sa6, Sa7, Sa8, NFAS A-Bit, NMFA Signal Results Signal loss (seconds), bit slips, RX level, TX and RX bit rate BERT Results Bit errors (TSE), bit errorrate, errored seconds, error-free seconds, percentage error-free seconds, pattern slip, roundtrip delay, pattern loss seconds (LFF) Audio Monitor From RX1, RX2, or RX1 and RX2 Round Trip Delay Range 0-10 s Resolution 100 µs Result Categories Summary, LED, Signal, Frame Data, Timeslot, BERT, Performance (G.821, G.826ISM, G.826 OOS, M.2100ISM, M.2100 OOS), Time, Event Table, Event Log, Event Histogram Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Powers Your Online Marketplace Grow your business, not your staff with Kyozou eBay Management Software
