Kkmoon Xr2206 High Precision Function Signal Generator Diy Kit Sine/triangle/...

US $2100

  • US, United States
  • Oct 20th
Open on mobile:
QR code
KKmoon XR2206 High Precision Function Signal Generator DIY Kit Sine/Triangle/Square Output 1Hz-1MHz Adjustable Frequency Amplitude Product Features High resolution, can generate sine/triangle/square waveforms. Frequency range: 1Hz-1MHz. Adjustable frequency and amplitude. Frequency adjustment features coarse tuning and fine tuning. Wide power supply range, use 9-12V external power or 9V battery(NOT Included). All are through hole components, easy for installation. Product Specifications Part Number: BOG0174128036989YT Item Weight: 3 ounces Product Dimensions: 6 x 4.7 x 0.8 inches Shipping Weight: 3 ounces Date First Available: June 27, 2016 Why Buy From JandJ Ultra? Highly Trusted Seller Over 99.7% Positive Feedback FAST Shipping and Tracking HUGE Discounts Excellent Returns Policy The BEST Customer Service Shipping & Returns We Ship International! 14 Day Money Back Return Policy Items Ship within 24-48 Hours Product Description This signal generator DIY kit is professional product to generate sine/triangle/square wave. It's a DIY kit for you to weld and install. Specifications Voltage Supply: 9-12V DC Input Waveforms: Square, Sine & Triangle Impedance: 600 Ohm + 10% Frequency: 1Hz-1MHz SINE WAVE Amplitude: 0-3V at 9V DC Input Distortion: Less than 1% (at 1KHz) Flatness: +0.05dB 1Hz - 100kHz SQUARE WAVE Amplitude: 8V (no load) at 9V DC Input Rise Time: Less than 50ns (at 1KHz) Fall Time: Less than 30ns (at 1KHz) Symmetry: Less than 5% (at 1KHz) TRIANGLE WAVE Amplitude: 0-3V at 9V DC Input Linearity: Less than 1% (up to 100KHz) 10mA Package Size: Approx. 12 8 2cm / 4.72 3.15 0.8in Package Weight: 69g / 2.46oz What is in the box 1 Signal Generator DIY Kit 1 User Manual(English) Thank You For Your Business!
