Leadshine Stepper Motor 86hs Nema34 86hs35 (bipolar)parallel 4.0a 495.6(3.5)n.m

US $138.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 2-phase Stepper Motor 86HS NEMA34 Series 86HS35 (Bipolar)Parallel 4.0A 495.6(3.5)N.M New Introductions: The 86HS35 two-phase stepper motor is suitable for a wide range of motion control applications. Terminated with 8 motor leads, the motor can be connected in a few different ways, including bipolar series, bipolar parallel and unipolar. Features: *2-phase hybrid step motor *High torque design *Standard NEMA 34 dimensions *Series or parallel and unipolar wiring *Optimized for microstepping Specifications: General Step Angle 1.8° Step Angle Accuracy +5%(full step, no load) Temperature Rise 80°CMax Ambient Temperature -10°C -- +50°C Insulation Resistance 100M?min.500VDC Dielectric Strength 500VAC for one minute Shaft Radial Play 0.06 Max.(450g-load) Shaft Axial Play 0.08 max.(450g-load) Number of Leads 8 Electric Model Number Connection Holding Torque Oz-in (Nm) Phase Current (Amps) Phase Resistance (Ohm) Phase Inductance (mH) Rotor Inertia Oz-in-sec2 (g*cm2) 86HS35 Bipolar (Parallel) 495.6(3.5) 4.0 0.7±10% 3.9±20% 0.0142(1000) Bipolar (Series) 495.6(3.5) 2.0 2.8±10% 15.6±20% Unipolar 311.52(2.2) 2.8 1.4±10% 3.9±20% Matching drives: Model Match drives 86HS35 EM705/EM806/DM870/DM1182 86HS45 86HS85 EM705/EM806/DM870/DM1182/ DM2282 Applications: Suitable for all kinds of small automation equipment and instruments, such as: pneumatic marking machine, marking machine, cutting machine, laser marking machine, plotter, small engraving machine, CNC machine tools, handling equipment, etc. The efficiency is very high for the users who expect low vibration, little noise, high precision and high speed small equipments. Other hot items of this Leadshine 2-phase stepper motors for above applications: 35HS01 Leadshine 2-phase Stepper Motor 35HS NEMA14 Series 35HS01 0.4A 0.07N.M New 39HS02 Leadshine 2-phase Stepper Motor 39HS NEMA16 Series 39HS02 0.6A 0.22N.M New 42HS02 Leadshine 2-phase Stepper Motor 42HS NEMA17 Series 42HS02 0.4A 0.22N.M New 57HS04 Leadshine 2-phase Stepper Motor 57HS NEMA23 Series 57HS04 (Bipolar)Series 2.0A 56.64(0.4)N.M New 57HS09 Leadshine 2-phase Stepper Motor 57HS NEMA23 Series 57HS09 (Bipolar)Parallel 4.2A 184.08(1.3)N.M New 57HS13 Leadshine 2-phase Stepper Motor 57HS NEMA23 Series 57HS13 (Bipolar)Parallel 4.0A 254.88(1.8)N.M New 57HS22 Leadshine 2-phase Stepper Motor 57HS NEMA23 Series 57HS22 (Bipolar)Parallel 5.0A 283.2(2.0)N.M New 86HS35 Leadshine 2-phase Stepper Motor 86HS NEMA34 Series 86HS35 (Bipolar)Parallel 4.0A 495.6(3.5)N.M New 86HS45 Leadshine 2-phase Stepper Motor 86HS NEMA34 Series 86HS45 (Bipolar)Parallel 6.0A 637.0(4.5)N.M New 86HS85 Leadshine 2-phase Stepper Motor 86HS NEMA34 Series 86HS85 (Bipolar)Parallel 6.0A 1203.6(8.5)N.M New 110HS12 Leadshine 2-phase Stepper Motor 110HS NEMA42 Series 110HS12 Parallel 6.0A 12N.M New 110HS20 Leadshine 2-phase Stepper Motor 110HS NEMA42 Series 110HS20 Parallel 6.0A 20N.M New 110HS28 Leadshine 2-phase Stepper Motor 110HS NEMA42 Series 110HS28 Parallel 6.5A 28N.M New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	86HS35
Model	86HS35
Country of Manufacture	China
