Micro Lathe Ii Model 4500

US $5700

Saint Augustine, Florida, United States
May 2nd

Open on mobile:
QR code

Micro Lathe II has seen very little use over the years of my building model airplanes. It comes with ten cutting tools and two center drills, plus a copy of the operations manual. This model does not have the Powerfeed carriage travel option currently offered by Taig manufacturer. Prepaid Shipping, a $50.00 value! Shipped by ground transportation from Florida - Probable Shipping time 5 to ten days depending on your location. Current Taig Ad description Taig Tools - Desktop Milling Machines and Lathes. The MicroLathe II is a machine you don't have to baby. It is a rugged and precision machine. The MicroLathe II has a machined, ground and stabilized steel bed. It has two sealed ball bearings in its spindle, coupled with a six speed positive vee belt drive. The spindle speeds are set in a geometric progression from 525 to 5200 RPM. A precision machine with the capabilities to 'HOG' 1/8 inch cuts in mild steel yet 'Dust' a few tenths, make the MicroLathe II a very versatile machine. Some big lathe features include large 0.001 inch graduations on the cross slide dial, adjustable tool post and carriage depth stop. With adjustable brass gibs providing full compensation for carriage and cross slide wear, it all adds up to the BEST VALUE in small lathes! MicroLathe II basic unit shown (less Powerfeed) with 3-Jaw Chuck (1050), Boring bar (1097E), Tailstock (1150), Drill Chuck (1091), 1/4 HP 1725 RPM Motor (1021w), Motor Mount Bracket (1022), Mounting Board (1023), and Pulleys (1162 with 3M 500 belt). Price as shown $489.10 SPECIFICATIONS GENERAL Overall working accuracy 0.0005 in. Max. headstock normality to bed 0.0004 in. Max. taper bed dovetails over pins 0.0001 in. Cross slide screw 1/4 - 20 Max. spindle speed recommended 7000 RPM Length of headstock on ways 2.625 in. Width of cross slide on carriage 2.000 in. Maximum bearing runout 0.0004 in. Max.cross slide normality to bed 0.0004 in. Cross slide dial graduation 0.001 in. Carriage travel 0.600 in. per 1 rev. of handwheel. Pulley type std. 5/8 in. bore multi-stop vee belt. Length of carriage on ways 3.000 in. Bed dovetails 45 deg. CAPACITY Max. turning dia. 4.5 in. (extendable to 6.5 in.) Swing over cross slide 2.375 in. Overall length of bed 15.5 in. Overall length of lathe 16.5 in. Tool bit size standard 1/4 in. Drill chuck capacity 1/4 in. Distance between centers 9.75 in. (with tailstock). Carriage travel 9.0 in. Cross slide travel 1.75 in.

“Good Condition”
