NE555 Pulse Frequency Duty Cycle Adjustable Signal Generator Module Square Wave, US $3.39 – Picture 0
NE555 Pulse Frequency Duty Cycle Adjustable Signal Generator Module Square Wave, US $3.39 – Picture 0

Ne555 Pulse Frequency Duty Cycle Adjustable Signal Generator Module Square Wave

US $3.39

  • ??, ???, China
  • Jan 29th
Open on mobile:
QR code
NE555 Pulse Frequency Duty Cycle Adjustable Signal Generator Module Square Wave ·        Main chip: NE555; ·        Input Voltage: 5V-15VDC. when power supply is 5V , the output current can be 15MA around;when 12V power supply, the output current can 35MA around; ·        Input current: >=100MA ·        Output amplitude: 4.2V V-PP to 11.4V V-PP. (Different input voltage, the output amplitude will be different) ·        Maximum output current: >=15MA (when 5V power supply, V-PP greater than 50%), ·                                                >=35MA (when 12V power supply, V-PP greater than 50%)     ·        Output with LED indication (low level ,LED will on; high level, LED will off; low frequency, the LED flashes); ·        the output with LED indication, there is no straightforward output (low level LED volume, high LED off, LED flashes when the frequency is low); ·        the output frequency range of grades available, the output frequency is more continuously adjustable; ·        Low-profile: 1Hz ~ 50Hz ·        IF file: 50Hz ~ 1kHz ·        High-frequency profile: 1KHz ~ 10kHz ·        High Frequency file: 10kHz ~ 200kHz ·        you can fine-tune the output duty, duty cycle and frequency are not separately adjustable, adjust the duty cycle will change the frequency
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand new
Country/Region of Manufacture China
Model ne555
