Omron E5C4-R20J Temperature Controller (NEW-Made In Japan), US $95.00 – Picture 0
Omron E5C4-R20J Temperature Controller (NEW-Made In Japan), US $95.00 – Picture 1
Omron E5C4-R20J Temperature Controller (NEW-Made In Japan), US $95.00 – Picture 0
Omron E5C4-R20J Temperature Controller (NEW-Made In Japan), US $95.00 – Picture 1

Omron E5c4-r20j Temperature Controller (new-made In Japan)

US $95.00

  • South Richmond Hill, New York, United States
  • Jun 9th
Open on mobile:
QR code
Specifications Ratings Supply voltage 100/110, 200/220, 110/120, 220/240 VAC, 50/60 Hz Operating voltage range 90% to 110% of rated supply voltage Power consumption Approx. 2 VA Input Thermocouple (with sensor burnout detection circuit) or platinum resistance thermometer Control mode ON/OFF or P control Setting method Digital setting Indication method Digital indication Control output Relay output: SPDT, 3 A at 250 VAC, resistive load (switching capacity: 330 VA) Voltage output for SSR: 10 mA at 5 VDC (with short-circuit protection) H: 5±1 V; L: 0.5 V max. Characteristics Setting accuracy ±2% FS max. Indication accuracy ±2% FS max. Indication range Within set temperature range Hysteresis Approx. 0.2% FS (fixed) Proportional band 3% FS (fixed) Proportional period Relay output: Approx. 20 s Voltage output: Approx. 2 s Reset range (see note 1) ±1.5% FS min. (variable) Insulation resistance 20 M? min. (at 500 VDC) Dielectric strength 2,000 VAC, 50/60 Hz for 1 min between charged terminals and uncharged metallic parts Vibration resistance Malfunction: 10 to 55 Hz, 0.3-mm double amplitude for 10 min each in X, Y, and Z directions Destruction: 16.7 Hz, 4-mm double amplitude for 2 hrs each in X, Y, and Z directions Shock resistance Malfunction: 147 m/s2 (15G), 3 times each in 6 directions Destruction: 294 m/s2 (30G), 3 times each in 6 directions Life expectancy Mechanical: 10,000,000 operations min. Electrical: 100,000 operations min. (3 A at 110 VAC, resistive load) Ambient temperature Operating: –10°C to 55°C (with no icing) Ambient humidity Operating: 45% to 85% Enclosure ratings Front panel: IEC standard IP40 (see note 2) Terminals: IEC standard IP00 Weight Approx. 200 g (with flush-mounting adapter)
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand OMRON
MPN Does Not Apply
Model E5C4-R20J
Country/Region of Manufacture Japan
