Orion Iiia Pro Gamma Spectrometer Mca, Hvps For Scintillation Radiation Detector

C $699.00

SASKATOON, Canada
Sep 3rd

Open on mobile:
QR code

Sohtech Orion IIIA PRO Gamma Spectrometer is our newest model for Year 2020! It makes high performance gamma spectrometry more affordable than ever before. We based our design on our highly successful Orion I to III, using a more quiet preamp and transimpedance circuitry, a 30% more powerful HV power supply using the latest technologies, added in a 1500V backlit voltmeter that can also be used to measure external devices, and new capability to accept two-wires type probes, all in a lightweight and sleek package. Orion IIIA PRO is so easy to use, you will obtain your first professional gamma spectrum fast and hassle free, typically within the very first hour you opened the box. Orion IIIA PRO lets you take advantage of the powerful yet user friendly Theremino & PRA MCA software, while overcoming the key hardware limitation of Theremino PMT adapter or other amateur grade gamma spectrometer system - the weak power supply that only works using scintillation probe with a voltage divider resistance of 100M or above. With such excessive voltage divider resistance, the current leakage between the photomultiplier terminals leads to the interstage voltage variation and an unstable spectrum that changes with time. Furthermore, not every scintillation probe has voltage divider circuit that is amenable to aftermarket modification, so users of such underpowered amateur systems are quite limited in their selection of usable probes. Orion IIIA PRO gives you the freedom, to use any positive polarity scintillation probe with BNC connectors and probe resistance down to 7M. You can vary the probe voltage precisely between 0 to +1100VDC via a 25 turns potentiometer. Take your gamma spectroscopy measurement anywhere with your laptop, tablet or desktop computer! The exceptional voltage stability and low ripple voltage of the internal power supply, in combination with the our advanced circuitry, gives you a solid spectrum that is only found in gamma spectroscopy systems that cost many times more. Technical Specifications: Input Power + 5V (USB 2.0/ 3.0/ 3.1) Current Draw < 150 ma Output Bias Voltage 0 to +1100VDC Minimum Probe Resistance/ Load 7MOhm at +1100VDC ADC Sample Rate/Bit rate 48kHz/16 Bit Signal to Noise ratio 85 dB Pulse length Optimized at 100µs Voltage Drift < 1:1000V High Voltage Connector BNC Signal in Connector BNC Dimension 125mm L x 106mm W x 60mm H Sohtech Orion IIIA PRO Gamma Spectrometer comes with: Sohtech Orion IIIA PRO Gamma Spectrometer/ Digital Multi-Channel Analyzer 0 to +1100 VDC Supports probe resistance down to 7M Two BNC connectors to support either single wire or two wires type scintillation detector 48KHz Sampling Rate/ 16-Bit ADC 85dB Signal-to-Noise Ratio Premium genuine Hammond lightweight aluminum enclosure with durable clear anodized finish 1500V Voltmeter with backlighting 1G input impedance 1V Resolution Switchable to measure external device span style="font-family: Arial, sans-serif;">Minimal loading on device under test Software loaded with powerful features and professional interfaces Automatic nuclide identification Real time pulse visualization Background subtraction FWHM analysis 6 feet long gold plated shielded USB cable Sohtech Orion IIIA PRO Gamma Spectrometer Quick Start Guide, Calibration Report, Cs-137 FWHM Report and System Calibration files 30 days warranty (Optional extended warranty available) System Requirement: A computer, tablet, laptop or netbook with a USB port compatible with Theremino (Windows XP to 10/ Linux/ OSX with Wine), or PRA (Windows) MCA software Note: Laptop, netbook, scintillation probe and gamma ray sources shown are not included. The Sohtech Orion Gamma Spectrometer works great! See it in action here: https://youtu.be/-veG8nelgcs/?vq=hd1080 About the seller (in case you are interested): Tedric Soh (M. Eng. in Material Eng., B. Eng. in Metallurgical Eng.) was a former member of the Radiation Safety Advisory Committee at the University of Saskatchewan. I have years of experience working with SLOWPOKE-II Research Reactor performing fission and neutron activation experiments, as well as designing and fabricating custom GBq strength radioisotope sources. I am here to help if you have any question on the system. Due to our continous product improvement program, the Sohtech Orion IIIA Gamma Spectrometer is a make to order high quality instrument that features the latest technologies, and is ready for shipment within 10 business days, make it yours today! Express shipping, optional MHV and SHV connectors are also available. Buy with confidence, we have been on eBay for over 16 years with many satisfied customers and 100% positive feedback. Our goal is to provide you with great quality laboratory products and professional service at affordable price. Feel free to contact us with any question you may have. Canadian GST and SK PST apply where applicable. Thank you for your interest and please check out our other cool items too.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ORION IIIA PRO (MCA only, probe not included)
Non-Domestic Product	No
Modified Item	No
Type	Radiation Detector (MCA only, probe not included))
Country/Region of Manufacture	Canada
MPN	Orion IIIA Pro
Custom Bundle	No
Brand	Sohtech
Radiation Detector Type	Scintillation Detector (MCA Only)
