Oxford Tennelec Tc 175 Preamplifier Proportional Counters Radiation Detector

US $245.01

Santa Fe, New Mexico, United States
Jan 30th

Open on mobile:
QR code

Oxford Tennelec TC 175 Low Noise Preamplifier for Proportional Counters This is an Oxford Tennelec TC 175 charge sensitive FET preamplifier with instruction manual. The TENNELEC Model TC 175 FET Charge-Sensitive Preamplifier was specifically designed for use with proportional counters requiring up to 5kV of bias. The TC 175 can also be used with room-temperature silicon surface barrier detectors and scintillation counters which use low-gain photomultipliers (or standard scintillation counters in the x-ray range of energies). The TC 175 output signal is compatible with all commercially available main amplifiers which use conventional pulse shaping networks—the TC 175 does NOT have a shaping network of its own. The input FET is fully protected against rapid or large changes in detector bias supply voltage and protected to a lesser degree against accidental short circuits at the input connector while bias voltage is applied. The background count due to corona in the preamplifier is guaranteed to be less than 10 c.p.m. at a threshold of 100X the rms noise level. Below 5 kV, the background due to corona drops rapidly and is essentially zero at 2kV. The rms noise level is equivalent to 15 eV at an effective gas multiplication factor of 1,000 (P-10 gas) when the external capacitance is 20 pF and the amplifier shaping constant is 4 μs. The input coupling capacitor is a polystyrene film unit to eliminate the piezo electric ringing characteristics of ceramic capacitors. Applications Proportional counters Room-temperature silicon surface barrier detectors Low-gain scintillation detectors X-ray scintillation detectors Click Here to Download More Info Specifications Maximum DC Operating Voltage 5 kV Output Impedance 50 Ω Output Decay Time 220 μs Output Polarity Inverse of input polarity CHARGE SENSITIVITY 200 mV/pC Input and Bias Connectors SHV Output Connector BNC Test Connector BNC Retail Price $1,244.61 Inspection by a Hofstra Group technician allows us to guarantee this hardware to perform to your satisfaction. This item carries a 7-day unconditional right of return and a 90-day warranty. In the unlikely event that you need to return it, we will arrange and pay for return shipping in addition to refunding the purchase price and original shipping. Please review our Sales Agreement for more information. Please note that export of this item is controlled for some countries. Export is possible, but may require a license. It is not guaranteed that a license will be granted by the BIS, in which case the sale will be canceled. Please enquire for details. _gsrx_vers_586 (GS 6.8 (586))
