pneumatic pancake cylinder for sale, brand-new and used.

NEW BIMBA PANCAKE 5" AIR PNEUMATIC CYLINDER FT-095 This is for a New Pneumatic Bimba Pancake Air Cylinder, Model # FT-095 with 5" of stroke, 1 1/16" Bore with two 1/4" pistons. Flat-II nonrotating, double-acting cylinder provides the answer to applications where rotation cannot be tolerated and space is at a minimum. Nonrotation is achieved with dual piston rods and a rod end block that insures the rods work in tandem.

You are bidding on a Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinders with Screw clearance holes both ends, Model # FO-09-0.5 with 1/2 Inch of stroke, 1 1/16" Bore, and a 1/2" piston. Cylinder measures 1 3/8" High x 2" Diameter. Features Force is .9 x air pressure Body - 304 Stainless Steel Heads - Anodized Aluminum Alloy Piston Rod - Ground and Polished 303 Stainless Steel Piston Seals - Buna N Rod Bushing - Oil Impregnated Bronze

NEW BIMBA 3/4" PANCAKE AIR PNEUMATIC CYLINDER FO-090.75-4MTV You are bidding on a New Pneumatic Bimba Double Acting Pancake Air Cylinder, Model # FO-090.75-4MTV with 3/4 Inch of stroke, 1 1/16" Bore, and a 1/2" Male rod end piston. Cylinder measures 1 5/8" High x 2" Diameter. Featur

NEW BIMBA PANCAKE 1" AIR PNEUMATIC CYLINDER FT-091-MP3 This is for a New Pneumatic Bimba Pancake Air Cylinder with magnetic sensing, Model # FT-091-MP3 with 1" of stroke, 1 1/16" Bore with two 1/4" pistons. Flat-II nonrotating, double-acting cylinder provides the answer to applications where rotation cannot be tolerated and space is at a minimum. Nonrotation is achieved with dual piston rods and a rod end block that insures the rods work in tandem.

NEW BIMBA PANCAKE 1" AIR PNEUMATIC CYLINDER FO-041-3FHDLM4 You are bidding on a New Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinder with Screw clearance holes back and mounted holes front - with magnetic sensing, Model #FO-041-3FHDLM4 with 1 Inch of stroke, 3/4" Bore, and a 5/16" piston. Cylinder measures 2 1/2" High x 1 1/2" Diameter. Features Force is .4 x air pressure Heavy duty rear head Body - 304 Stainless Steel Heads - Anodized Aluminum Alloy Pist

NEW BIMBA PANCAKE 3/4" AIR PNEUMATIC CYLINDER FO-17-0.75-MT This is a New Pneumatic Double Acting Bimba Pancake Air Cylinder, Model # FO-17-0.75-MT with 3/4" of stroke and a 5/8" piston with male thread - 1 1/2" Bore. Cylinder measures 1 5/8" High x 2 5/8" Diameter. This cylinder will exert a force of approximately 1.7 times the air line pressure.

You are bidding on up to 3 Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinders with Screw clearance holes both ends - with magnetic sensing, Model #FO-041-M with 1 Inch of stroke, 3/4" Bore, and a 5/16" piston. Cylinder measures 2 1/2" High x 1 1/2" Diameter. Each bid is for ONE Cylinder.

BIMBA 1.25" PANCAKE AIR PNEUMATIC CYLINDER FO-311.25-4F This is a Pneumatic Bimba Large Pancake Air Cylinder, Model # FO-311.25-4F with 1 1/4" of stroke with a 3/4"(.750) piston. Cylinder measures 2 1/4" High x 3 1/8" Diameter. This cylinder has a 2" Bore and the exerted force is 3.1 times the air pressure - 100 psi will produce 310 lbs of exerted force.

NEW BIMBA PANCAKE AIR PNEUMATIC 3" STROKE 1 1/2" BORE CYLINDER FO-173-3RM This is a New Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinder with Magnetic sensing, Model # FO-173-3RM with 3 Inches of stroke with a 5/8" piston. Cylinder measures 4 3/4" High x 2 5/8" Diameter.

NEW BIMBA PANCAKE AIR PNEUMATIC 3" STROKE 1 1/2" BORE CYLINDER FO-173 This is a New Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinder, Model # FO-173 with 3 Inches of stroke with a 5/8" piston. Cylinder measures 3 7/8" High x 2 5/8" Diameter. Bimba Flat-1 cylinders are the shortest in length of all space-saving cylinders.

BIMBA 3/4" PANCAKE AIR PNEUMATIC CYLINDER FO-090.75 You are bidding on a Like New Pneumatic Bimba Double Acting Pancake Air Cylinder, Model # FO-090.75 with 3/4 Inch of stroke, 1 1/16" Bore, and a 1/2" piston. Cylinder measures 1 5/8" High x 2" Diameter. Features Force is .9 x air pressure Body - 304 Stainless Steel Heads - Anodized Aluminum Alloy Piston Rod - Ground and Polished 303 Stainless Steel Piston Seals - Buna N Rod Bushing - Oil Impregnated Bronze Rod Seals -

BIMBA 1/2" PANCAKE AIR PNEUMATIC CYLINDER FO-090.5 This is an Auction for a Pneumatic Bimba Double Acting, Double Acting Pancake Air Cylinder with Screw clearance holes bottom and top, Model # FO-090.5 with 1/2 Inch of stroke, 1 1/16" Bore, and a 1/2" piston. Cylinder measures 1 3/8" High x 2" Diameter. Features Force is .9 x air pressure Body - 304 Stainless Steel Heads - Anodized Aluminum Alloy Piston Rod - Ground and Polished 303 Stainless Steel Piston Seals - Buna N Rod Bushing -

You are bidding on a Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinder with Screw clearance holes top and Bottom tapped holes, Mode

This is an Auction for a New Pneumatic Bimba Double Acting, Single End Rod Pancake Air Cylinder with Magnetic Sensing and Screw clearance holes bottom, Model # FO-

NEW BIMBA PANCAKE 2" A

FABCO-AIR DOUBLE END 2" BORE 1/2" PANCAKE AIR CYLINDER B-321-X-U This is an Auction for a Double Acting Pneumatic Fabco-Air Pancake Air Cylinder, Model # B-321-X-U with 1/2" of stroke with a 3/4" piston - 2" Bore.

NEW BIMBA 3" PANCAKE AIR CYLINDER DOUBLE END FOD-17-3 This is a New Pneumatic Bimba Pancake Double Acting - Double End Air Cylinder, Model # FOD-17-3-3-U with 3 inches of stroke with a 5/8"(.625) piston. Cylinder measures 2 5/8" Diameter and has a 1 1/2" bore. Power Force - 1.7 times air line pressure.

BIMBA PANCAKE 2.5" DOUBLE END AIR CYLINDER FOD-092.5 This is a New Pneumatic Bimba Double End Pancake Air Cylinder, Model # FOD-092.5 with 2 1/2 Inches of stroke with a .500" piston. Cylinder Body measures 2" Diameter x 3 1/2" High with 1 1/16" Bore. Force exerted is .9 time air pressure.
