Rf Microwave Dual Stub Tuner 800 Mhz - 4000 Mhz / High Power 100 Watt / Tested

US $220

Sunnyvale, California, United States
Jun 17th

Open on mobile:
QR code

Auctiva's FREE Scrolling Gallery will enhance your listings. All items in Telenochek RF store are categorized with extensive detailed categories to simplify searching through the items. Be sure to take advantage of the detailed categories! For sale is: RF, microwave dual stub tuner in good working condition. Please see pictures and data table. This tuner has locking nuts. **Every individual item is tested prior to shipment** A multi-stub tuner is a very useful and versatile device for matching a complex load to 50 ohm, or introducing a mismatch if desired. Due to inherent high power handling, stub tuners are especially valuable in high power applications where the matching needs to be achieved in a high power RF path with minimal signal loss. Note on dual stub tuners vs. triple stub tuners. Dual stub tuners: Dual stub can typically match a wide variety of loads. Contrary to popular belief that dual stub tuners can match every load, there exists a forbidden region of loads at some frequencies / high VSWR values when using dual stub matching. One workaround in the lab / test environment is to add one more variable - the length of transmission line between the dual stub device and the load. This can be accomplished easily in the lab by having different short lengths of low loss cable, or low loss adapters. Once an appropriate length of line has been inserted, the load impedance is transformed to a region the stub tuner can match easily. Triple stub tuners: Triple stub tuners add the third variable as the third stub and typically do not have forbidden region, and also allow matching over wider bandwidth. Type Tuner Dual Stub Manufacturer Maury Microwave Seller SKU TMRF_3B1 Port 1 N(f) Port 2 N(m) Insertion Loss (dB) 0.20 Low Frequency of Operation (MHz) 800 High Frequency of Operation (MHz) 4000 Stub Travel (in) 7.50 inch, has locking nuts Stub Spacing (in) 2 inch Power handling ( Watt CW) 100 Watt CW Notes: The tuner can be also be very useful outside the nominal frequency ranges. The lower frequency limit of a tuner is determined by the frequency at which the maximum stub travel equals 1/2 wavelength. In order to provide all possible shunt susceptances, each stub must be movable over 1/2 wavelength at the lowest frequency of operation. Note that many loads can still be perfectly matched at frequencies below the lowest frequency of operation using the tuner. However, when used out of specifications (e.g. below 2GHz), the tuner becomes more restrictive in terms of the variety of loads it can match. The upper frequency limit for a stub tuner is established by its connectors. Generic example of using a dual stub tuner with 0.5" stub spacing: Assume stub spacing is fixed at 0.5" (1.3cm) as per manufacturer specifications. Assume maximum stub travel is 3" (7.6cm) Load is chosen for this example with VSWR > 6, or reflection coefficient > 0.7, and return loss of 3dB. Matching Example at 4 GHz : ZL = 5.6 – j23.5 Ohm Stub1 travel = 0.53 cm Stub Spacing = 1.3 cm (0.5" inch) Stub2 travel = 1.1 cm Shipping: We always pack with care to ensure your item arrives in mint condition. To lower your shipping costs, we combine shipping for items purchased within several days. International shipping: An international shipping estimate is calculated by eBay, but is only an estimate. International customers please contact the seller for shipping price before bidding or purchasing. Buyer is responsible for all extra fees associated with international shipping, such as import and customs duties. Return policy: We work with our customers to resolve any issues they might have. Majority of our items have been professionally tested. Any known problems with components, equipment etc... will be noted in the item description. Thank you for your interest! Questions are invited! Please check out my store for similar items Additional search keywords: RF, microwave, MHz, GHz, broadband , wideband, megahertz, gigahertz, dual stub tuner, slug tuner, sliding tuner, triple stub, stub matching, transmission line matching. 1.3 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
