Smoothieboard 5xc V1.0a 3d Printer / Cnc / Laser Cutter Electronics - Super Fast

GBP 109.99

Cumbria, United Kingdom
Jan 30th

Open on mobile:
QR code

*** Fully Assembled and Tested 5XC Smoothieboard V1.0A *** Super fast and precise electronics system for 3D Printers, CNC machines, Laser cutters etc VERY EASY to use, much more so than any other system out there, see "features" below for more detail. Proffessionally manufactured in the UK with all components sourced from reputable suppliers, i.e. Digikey, Mouser, RS etc. Supplied assembled and tested with pluggable connectors, so you can use one board to run several different machines. Fully open source with a huge following, means firmware can be used for a wide range of applications, WITHOUT difficulty. Its Smooth!!!!! *** Features *** Click to Enlarge NXP LPC 1769 32-bits Cortex-M3 MCU Powerful enough to allow look-ahead acceleration management, resulting in smooth, jerk-free motion and enabling higher speeds. This is implimented in current firmware and simply not possible on Arduino type electronics. This makes Smoothiboard more precise and fast!!! Click to Enlarge EASY to configure and use Unlike other electronics / firmware combinations, making changes to the configuration is done by simply editing a single text file and reset-ing the board. What's more, the sd card shows up on your pc like any other attached drive so editing the text file is very quick and convenient. The config file is easy to understand, backed up with a "how to" wiki and even allows you to change the pins for each function so if you want to mod the hardware in some way, like use other unused pins for some of the functions, this can be done without modifying the firmware. The smoothieboard website has step by step guides for each machine type and is supported by a community of really helpful people making it very easy to understand if you are building your first machine or struggle with software side of things. When new firmware is available flashing it is as easy as copying the newer verision to your sd card, no external programmers or software required. Compare this to other systems where the user has to install additonal software, edit and re-compile / upload new firmware everytime a single setting needs altering. Forget about those stk500 errors and debugging code etc! Of course, if you like a challenge, you can download all the source (everything is open) and compile the firmware if you prefer. Click to Enlarge Onboard Ethernet, USB and sd card reader. All of which work out of the box! Just plug an sd card with the config file (easily found on the smoothie website), install the smoothieboard driver for your operating sytem (very easy as there is an installer on the smoothie website) and then it is ready to connect via USB. Or, after inserting the sd card (and enabling network connection in the config file) plug the board in to your router and connect via the web interface (no driver required!). Click to Enlarge Built in web server If you connect the smoothieboard to your router, you can access (and control) the board from your web browser, or if you perfer it works fine with normal PC based software like Printrun etc. We are working on an LCD panel at the present which will allow fully stand alone printing. Keep an eye on our other listings! Click to Enlarge 5x A4982 Stepper Motor Drivers The A4982 is the prefered stepper motor driver for Reprap type printers and is chosen for its 1/16 microstepping and overall good performance with up to 2A per motor. 5 drivers allow you to control a 3D printer with dual extruder. There are also breakout points on the board next to each stepper driver allowing you to connect other stepper drivers if for instance you needed a high current driver for a large motor on a custom machine. Click to Enlarge 6 MOSFETs A mixture of 3 low power ( 7A max for fans etc) and 3 high power (12A max for heat bed and two extruders) MOSFETs There are multiple options in the config file for the use of these MOSFETs including PID Autotuning. If you have a requirement to switch something very large (like a spindle for a CNC machine) you can easily attach a solid state relay to one of the free pins. Click to Enlarge High Quality PCB 4-Layer 2oz copper pcb with excellent thermal conduction from the stepper drivers which removes the need for extra heatsinks / fans. Click to Enlarge On board Digital Potentiometers The current for each stepper motor is controlled from the config file, no need for adjusting potentiometers and reading off multimeters. There are 3 spare digital pots and breakout pins for using them. Click to Enlarge High quality pluggable connectors throughout We have chosen to supply pluggable connectors for all functions allowing a single board to be easily transferred from machine to machine if you are thinking of building different types of machine and want to keep costs down. We will supply additional connector sets in our "other items" to make this easy. Our 5.0mm Pluaggable terminal blocks are rated to 15A and the 3.5mm up to 8A. Click to Enlarge Better choice of Endstop connectors One slight oversight in the origional design of this board is that the KK100 connectors used for the endstop connection are too close together, such that if you try to attach all 6 (keep in mind most peole only use 3) you have to force the connectors as there isn't a gap for them to move freely. We have chosen a combination of the KK100 and right angle pin headers which allow all 6 to be connected securely, without risk of damaging the connectors. Click to Enlarge Enstop plus cable included We will include a set of good quality microswitches and some twisted pair wire for the endstops. Click to Enlarge Big red button Its Big, its Red and it lights up! Other sellers don't include this button because it is expensive (similarly they don't all include the Ethernet conector either) but we think its just too cool to leave off. *** Options *** Click to Enlarge Motor Connectors: Pluggable Terminal Blocks 3.5mm Pluggable terminal blocks for motor connection Click to Enlarge Motor Connectors: KK100 Standard KK100 type connectors may be useful if you have Nema-17 motors which already have this connector type. We include the wire connector (and crimp terminals) as standard if you do not already have the connectors fitted. Click to Enlarge 5V Regulator Fitted - Additional ?3 Required if you plan to use without either connecting to USB or using an external 5V power supply. *** Questions? *** Did I forget to mention something? Just get in touch and I'll answer any query as quickly as possible. Business seller information Scitech Supplies LTD Contact details Cumbria United Kingdom Print version Terms and conditions of the sale If you are unhappy in anyway with our product, please get in touch with us at the first possible moment as we will do our best to put things right. If you item is faulty please return it to us and we will refund the full cost (including the original shipping cost) or replace the item with your agreement. If you change your mind and simply wish to return the item on that basis, the item must be in "as new" condition for a full refund (which does not include any shipping charges). Where the item has been damaged by the buyer, a reduced refund will be offered. Once again, please get in touch with us if you aren't happy for any reason. We always make an effort to help our customers and do right by them. Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 14 days You pay return shipping

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Smoothieboard
Country/Region of Manufacture	United Kingdom
MPN	Smoothieboard V1.0a 5XC
