Tektronix Tekranger2 Tfs3031 Sm Fiber Tekranger 2 Otdr

US $1,195.00

Toledo, Ohio, United States
Jun 9th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Tektronix TFS3031 TekRanger 2 SingleMode OTDR (BC# 20403) SM OTDR Source: 1310nm 1550nm SC Connector For Source (2) APC SM SC-SC Fiber Cables (4) Fiber Wipes AC Adapter/Charger Power Cord RS232 PC Interface Cable User Manual On CD-ROM Hard Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Tektronix TekRanger2 TFS3031 Singlemode 1310nm & 1550nm OTDR Dynamic Range: 1310 / 1550 nm : 30 / 28 dB Designed to stand the rigors of field work, while providing precise measurements on singlemode optical fiber systems in an economical form factor. Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Features & Benefits One-button Fully Automatic IntelliTrace Fiber Analysis Singlemode Distance and Loss Measurements Traceable to NIST Large, Backlit, High-resolution Display Keyboard Port and Optional Mini-keyboard RS-232 and Parallel Ports for Printing and PC Access Shock, Water and Dust Resistant Auto Echo Detection Selectable Splice Loss and Reflectance Thresholds Files are Compatible with FiberMaster™ OTDR, TARGET1™, PC Spreadsheets Context Sensitive Help Applications Installation and Acceptance Testing of Fiber Optic Networks Fiber Optic System Maintenance Testing Locating Optical Cable Faults During Restoration Optical System Documentation TekRanger 2 TFS3031 If your job is to install, maintain or restore optical fiber, the TekRanger 2 TFS3031 mini-OTDR with IntelliTrace™ Automated Fiber Analysis System is a rugged, easy-to-use, mini-optical time domain reflectometer (OTDR) that's built for you. It's designed to stand the rigors of field work, while providing precise measurements on singlemode optical fiber systems in an economical form factor. The IntelliTrace System Advantage IntelliTrace technology automatically adjusts and optimizes test parameters so you don't have to. Just press the Start/Stop button and it will provide the best possible resolution, while maximizing dynamic range to give you the most accurate measurements available in a mini-OTDR today. One IntelliTraceFilter acquisition provides consistent, repeatable and accurate results. The location, reflectance and loss of every splice appears quickly and clearly on the large, high-contrast display. The TFS3031 is the only mini-OTDR that can locate an event at 10 meters while also finding an end at 70 km away with the push of a single button. No need for multiple acquisitions to get a complete picture of your fiber, either with a displayed trace or an event table. You get greater productivity in labor with less training. Traceable Measurements The TekRanger 2 TFS3031 offers traceability on distance and loss measurements. This means that both the hardware and the software are included in our accuracy specifications. What this means to you is that you can count on the TFS3031 mini-OTDR to provide the most reliable and repeatable measurements of any OTDR in the world. Convenient Data Storage Test results can be stored in the TFS3031's ample internal memory or collected on the optional floppy disk drive. Microsoft Windows based TARGET1 software package gives you virtually unlimited flexibility when analyzing and documenting your spliced fibers. Easy System Software Updates The TFS3031's optional disk drive and RS-232 port permit updating of the unit's firmware in the field so you can easily keep up with the latest technology. Specifications Wavelengths 1310 nm ±20 nm, singlemode. 1550 nm ±20 nm, singlemode. Dynamic Range*1 Dynamic Range 1310/1550 nm (Opt. 06) 30/28 dB Readout Resolution - 25 cm minimum. Loss threshold: 0.02 dB. Loss resolution: 0.001 dB. Distance Measurements - Meters, feet, miles. OTDR Distance Range Settings - Singlemode: 1 to 240 km. Distance Resolution (IntelliTrace™) - 1.25 m to 40 m. Hardware Scale Accuracy*3 - Horizontal Time Base: ±1.25 m ±1.25 m ± 10-5 x distance. Vertical Linearity: 0.02 dB/dB. System Measurement Accuracy*4 - Distance: ±4 m. Loss: ±0.01 dB. Reflectance Accuracy - Exceeds Bellcore GR-196-CORE*2. Measurement Time (Auto) - Less than 3 minutes (20 dB loss). Dead Zone*2 Event Loss Measurement Singlemode 5 m 15 m Display - High resolution 640 x 480; 7.2 in., high contrast; operator switchable backlight. Selectable Pulse Widths - 1 m, 5 m, 10 m, 20 m, 50 m, 100 m, 200 m, 500 m, 1000 m, 2000 m. Memory Capacity - 100 traces in internal memory (typical). 3.5 in. floppy disk drive (optional). Output Ports - RS-232 serial; Centronics parallel printer, mini-DIN (keyboard). Power Options - AC (100 to 240 V, 50 to 60 Hz). DC Operation: 9 to 16 VDC. Internal NiCad rechargeable battery (4 hours of operation depending on operating mode). Laser Safety - Class 1 per 21 CFR 1040. Class 1 per CEI/IEC 825-1: 1993. Options 3T, 4T and 7T are Class 1. Option 6T is Class 2. Environmental (without internal disk drive) Temperature Range - Operating: -10 °C to +40 °C. Nonoperating: -20 °C to +60 °C. Storage Temperature - -20 °C to +60 °C. Relative Humidity - 5% to 95% (noncondensing). Field Usage*2 - Shock, water and dust resistant. Shock*2 - 30 in. drop. Safety - UL 3111-1, CSA 1010.1. Physical Characteristics Dimensions cm in. Weight kg lbs. Width 29.2 11.5 Height 11.4 4.5 Depth 24.1 9.5 Net 4.2 9.2 *1 Typical performance @ 25 °C. *2 Per Bellcore GR-196-CORE. *3 Excludes uncertainty in fiber IR and cabling factor. *4 Verified on NIST traceable calibration system, singlemode options only. Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Reach your goals with Kyozou eBay Selling Tools

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Tektronix
MPN	TFS3031
Model	TekRanger 2
