Th2622 Heldhold Capacitance Meter Lcd Dual-display Max.measurement Accuracy 0.5%

US $190.00

???, ???, China
Jun 9th

Open on mobile:
QR code

Introduction TH2622 handheld capacitance meter adopts ultra-low consumption design and high density SMD technology. Its measurement range can be automatically switched. The capacitance measurement range is up to 199.99mF, maximum reading 11,000. Gorgeously once molded dual-color shell, dual-display LCD screen and easy operation are the characteristics of the meter. With USB communication interface, TH2622 can conveniently make data communication with PC and realize remote control. In order to meet the increasing test requirement for SMD, Tonghui provides optional TH26029C SMD test tweezers. Features · Measurement accuracy up to 0.5% · Gorgeous dual-color cast shell · Dual-display LCD with backlight · 4 1/2 digits display, maximum readings up to 11,000 · Measurement range from 0.1pF to 199.99mF · Constant current charge/discharge test method · Auto/Manual range selection · 25 sets of HI/LO limit comparison setup · 4 tolerance comparator modes: 1%,5%,10%,20% · Relative function · Data hold and Max/Min/Average statistic functions · Overload fuse protection function on input terminal · Low power consumption, typical working current: 6.5mA · Standard Mini-USB communication interface,SCPI commands compliant · Download FastGet PC communication software freely Specifications Measurement function Measurement parameters Capacitance(C) Range mode Auto/Manual Measurement terminal 3-terminal Tolerance mode 1%,5%,10%,20% Test input fuse 0.3A/220V fuse Communication interface Mini-USB(Virtual serial) Display Display screen LCD dual-display Backlight mode Menu setup Reading 4 1/2 digits display,maximum reading: 11,000 Max. measurement accuracy 0.5% (refer to accuracy specifications) Min. resolution of primary parameter Refer to accuracy specifications Power supply Battery model IEC 6LR61, 9V alkaline battery AC power adapter Input: 220V (1±10%), 50Hz(1±5%); Output: 12V-15V DC Working current Max:6.5mA Standby current Max: 2?A Battery life 70 Hours(typical) without backlight and based on new alkaline Auto Power off(only for battery mode) 0 to 99 min;factory default :15min Low Voltage indicator When battery voltage drops below 6V,low voltage indicator turns on General specifications Working temperature 0°C~40°C Working humidity

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TH
MPN	TH2622
Model	TH2622
