Th2822d Protable Handheld Lcr Bridge Basic Accuracy 0.1% 100hz-10khz Frequency

US $515.00

???, ???, China
Jun 9th

Open on mobile:
QR code

Introduction With its advanced impedance test technology, Tonghui has launched TH2822 series handheld LCR meters. This series currently possess the most powerful functions and outstanding performance in this industry comparable with bench LCR meters. Meanwhile it is the achievement of Tonghui after years of efforts and research in the passive-component testing field. TH2822 series apply the ultra-low power consumption design and high density SMD assembly techniques and can simultaneously display primary and secondary parameters on a LCD display with backlight. The dual-color shell is gorgeously once shaped; and functions are easy to operate. The test frequency is up to 100 kHz, the readings of primary parameter 40,000 counts and the resolution of dissipation factor 0.0,001. Accurate and convenient measurements of passive-components can be achieved in different occasions for a long time. In order to meet different market demand, multiple signal level and DCR test function are increased on TH2822D/E. The test accuracy can reach 0.1%. With USB interface, TH2822 series can conveniently communicate with a PC and be remotely controlled by a PC. In order to satisfy the increasing test requirements for SMD and balance the different needs for performance and price, two types of 4-terminal Kelvin test tweezers: TH26009C and TH26029C are optional for users’ choice. Features ? Max. Basic accuracy: 0.25% ? Maximum test signal frequency : 100kHz ? Selectable test signal level ? With DCR function ? Enhanced protection capability of input terminal impact ? 40000 counts for primary parameter, D/Q resolution 0.0001 ? Typical ultra-low consumption: 25mA ? Innovatively compatible terminal configuration: 5-terminal test slot and 3-terminal banana jack ? Intellectualized auto LCR function ? AC test speed up to 4 meas/sec (DCR: 3 meas/sec), fast automatic range switch design ? Constant 100? output impedance ? Percentage display and 4-tolerance comparator: 1/5/10/20% ? Battery charge in startup & shutdown ? Test terminal protection function ? Data-hold, Max./Min./Average value recording ? Real-time function configuration selection and working condition hold capacity ? Standard configuration Mini – USB communication interface and SCPI command set ? Free FastAccess PC communication software on our website ? Gorgeous dual-color cast shell Specifications Type TH2822D TH2822E Function Measurement parameters Primary Parameters: L / C / R / Z / DCR Secondary Parameters: D / Q / R / ? / ESR Equivalent Circuits Serial,Parallel Auto LCR Function Manual /Auto Ranging Mode Auto Test terminals 3-terminal?5-terminal Measuring Speed 4times/sec,1.5times/sec DCR 3times/sec Correction short?Open Tolerance Mode 1%,5%,10%,20% Input protection fuse 0.1A / 250V Interface Mini-USB(virtual serial port) Test Signal Signal frequency 100Hz, 120Hz, 1kHz,10kHz 100Hz, 120Hz, 1kHz,10kHz,100kHz Test signal level 0.3 Vrms, 0.6 Vrms, 1 Vrms Output impedance 100? Display Display LCD primary-secondary dual display with backlight Readings Max. Counts of Primary Parameter:40,000; D / Q Min. Resolution of secondary parameter: 0.0001 Basic accuracy 0.1% Display range L 0.00?H-1000.0H 0.000?H-1000.0H C 0.00pF-20.000mF 0.000pF-20.000mF Z/R 0.0000?-10.000M? DCR 0.0000?-20.000M? ESR 0.0000?-999.9? D 0.0000-9.999 Q 0.0000-9999 ? 0.00°-±180.0° Power supply Battery model LH-200H7C,8.4V Ni-MH 200mAH rechargeable battery AC Adapter Input :220V/50Hz;output :12V-15V(100?load) Standby(power off)Current 11?A Battery Life 16hours(typical)based on backlight off and new alkaline Auto Power off(valid for battery powered) 5min, 15min, 30min, 60min, OFF available;factory default:5min Low Voltage indicator when battery voltage drops below 6.8V,Low Voltage Indicator turns on

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TH
MPN	TH2822D
Model	TH2822D
