The Involute Gear Explained By Fellows Gear Shaper - 1936 - Reprint

US $9.98

Mebane, North Carolina, United States
Jan 30th

Open on mobile:
QR code

The Involute Gear, Simply Explained, published by The Fellows Gear Shaper Co., Springfield, Vermont, revised edition, 1936 copyrighted in 1930. Reprinted by Nation Builder Books, Leesburg, VA, 2002, 5 1/2 x 8 1/2 softcover, 63 pages. In the early 1900, the Fellows Gear Shapers applied a breakthrough in the mathematical and geometrical understanding of gear design to the problem of cutting gears, making possible mass production of reduction gear devices at relatively low cost. What better explanation of the involute gear can there be, than that given by the Fellows Gear Shaper Co. The sub-title of this little gem reads, ''A direct concise treatise which makes plain the action of involute gearing and yet avoids the use of higher mathematics.” Very well illustrated with crisp line drawings. Contents: The Function of Gearing, and Application of the Involute Gear A Gear Problem The First Suggestion The Second Suggestion The Third and Final Suggestion The Involute Gear, and its Application to Gear Teeth Another Method of Tracing an Involute Gear Method of Drawing an Involute Gear Transmitting Rotary Motion Through Involute Curves Using the Involute Curve for Gear Teeth The Line of Action Gear-tooth Shapes and Advantages of Involute Gears The Involute Rack Tooth The Involute Rack Tooth is Straight-sided Effect of Pitch Point Position on Pressure Angle Action of Involute Gears at Varying Center Distances Variable Pitch Diameters and Pressure Angles Fundamental Laws of the Involute Gear Involute Curve not Limited in Length Pressure Angle Depends on Portion of Involute Employed Involute Gear Tooth Interference Overlap of Tooth Action Slippage of Involute Gear Teeth Relation of Pressure Angle to Interchangeability Relation of Pressure Angle to Bearing Loads Generating Involute Gear Teeth Avoiding Interference in Involute Gearing The Gear Shaper Cutter as an Example of Correct Involute Action The Relief of the Gear Shaper Cutter Cutting Different Pressure Angles with the Same Cutter Definitions and Proportions of Gear Tooth Elements Definitions Gear Tooth Proportion Rules and Formulas Gear Tooth Parts Conversion of Millimeters into Inches Chordal Tooth Thickness and Chordal Addendum Please note this is a new photoduplicated reproduction, not an original.
