Ttc / Acterna T-berd 211 T1 Analyzer With Options 1 & 2 Jdsu

US $1,600.43

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! Acterna / TTC T-Berd 211/1/2 T-Carrier T1 Analyzer Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from TTC and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is guaranteed to work for 30-days, parts and labor, excluding freight. Option Information: Options 1: G.821 Analysis Option Options 2: Spectral Analysis Option - Isolateds network jitter problems. T-Berd T-Carrier Analyzer Features: Automatic configuration and results summary Automated sequences of test patterns for one-step circuit qualification and stress tests Pulse shape analysis, signal level and frequency, simplex current, and wander measurements Out-of-band ESF loop codes standard Wideband and high band jitter measurement Specifications: Operating Modes: Self Test, Automatic Configuration, T1 Unframed, T1 D4 Framed, T1 ESF Framed, T1 SLC Framed. T1C Test Loopback, Auxiliary Patterns: All Ones, 1:1, 1:7, 2 in 8, 3 in 23, QRSS (T1 and T1C), 2^15 -1, 2^20 -1, 2^23 -1, User Pattern 1 (3-24 bits), User Pattern 2 (3-24 bits), BRIDGTAP(tm) Pattern Sequence, MULTIPAT(tm) Pattern Sequence, All Zeros Input and Output Connectors: Bantam, WECO 310, 15-pin D, BNC Input Impedance: Bridge: > 1000 ohms with ALBO Term: 100 ohms with ALBO DSX-MON: 100 ohms with AGC Receive Level: Bridge or term: +6 dBdsx to -35 dBdsx (T1), +3 dBdsx to -6 dBdsx (T1C) DSX-MON: +6 dBdsx to -24 dBdsx (T1), +3 dBdsx to -24 dBdsx (T1C) Level Measurement: +6 dBdsx to -40 dBdsx; +6 to -6, 0.1 dB resolution; -6 to -40, 0.5 dB resolution Frequency Measurement: 1 Hz resolutions; 5 ppm accuracy Transmit Timing Sources: Internal Clock, External Clock, Reference Clock, Recovered Clock Line Codes: AMI, B8ZS Loopback Codes: CSU, CSU Line (ESF), CSU Payload (ESF), NIU (FAC1, FAC2, FAC3), NIU Network (ESF), Programmable (3 to 8 bits) Jitter Measurement: Wideband: >/= 32 UI, 10 Hz to 40 kHz Highband: >/= 32 UI, 8 kHz to 40 kHz Spectral Analysis: >/= 32 UI, 10 Hz to 40 kHz Jitter Masks: CCITT O.171, PUB 41451, PUB 62411-1983, PUB 62411-1985, PUB 43801 Pulse Masks: CB 119 (ANSI T1.102), ANSI T1.403-1989 Wander Measurement: +99999 UI, 1 UI resolution Power Requirements: 115 VAC ±10%, 50 to 60 Hz Key Features and Benefits: Jitter Alarm and Trigger: Front panel indicator provides fast indentification of jitter problems. Isolate multiplexer and channel bank clock recovery problems with jitter measurements across the full 10 Hz to 40 kHz range. In-Band/Out-of-Band ESF Loopback Codes: Emulate and loopback network devices which accept either in-band or ESF out-of-band (datalink) loopback codes with ESF framing. B8ZS Detection ALL ZEROS Stress Pattern: Front panel indicator provides fast identifications of B8ZS encoded data. The ALL ZERO stress pattern identifies circuits not configured for or incompatible with B8ZS encoded data. Automated Pattern Testing: Detect elusive bridge taps with the BRIDGTAP(tm) automated stress pattern sequence. Perform qualification tests with the user-configurable MULTIPLAT(tm) stress pattern sequence. Pulse Shape Analysis: Evaluate customer premise and network equipment adherence to transmit signal pulse shape specifications. CSU / NIU Emulation: Isolate customer premise and network equipment from the circuit during installation and maintenance. Ease of Use: Auto configuration and results summary provide immediate indentification of framing, pattern, and error status without any required set-up. The vacuum fluorescent display is ideally suited for dimly lit testing environments. For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? For all international customers, the following terms and conditions shall apply: These commodities, technology, or software are to be exported from the United States in accordance with Export Administration Regulations. Diversion contrary to U.S. law is prohibited. Domestic customers must also agree to the following terms and conditions: For items shipped within the United States, MHz Electronics, Inc's performance shall occur entirely within the United States. Unless expressly agreed to by MHz Electronics, this shall not be a routed party transaction. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	Seller refurbished : An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes	“This unit is guaranteed to work for 30-days, parts and labor, excluding freight.”
