Vacuum Table 48" X 24" For Cnc Routers Vtz4824grid

US $799.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

VT6040GAL Vacuum Table 48” x 24” PVC Grid for CNC Routers VTZ4824GRID PVC Grid-Vacuum Table Maximum precision with high strength PVC Check out our Videos at: Clampusystems.com/Videos.html Buying tools is a matter of trust! This vacuum table is made from PVC. It’s over 3/4” thick. The larger number of round openings in the vacuum table are mounting locations to ensure flatness. These are deep enough to allow the fastener heads to be below the surface to avoid any tool travel. The two round openings with the material cleaned out around them are the vacuum locations. These are threaded with 3/4” dia. NPT threads for 3/8" fittings. The smaller holes found around the perimeter and in the center of each square are 1/4” diameter holes, approx. 1/4” deep for the location of 1/4” stop pins. This allows the user to locate repetitive machined parts just about anywhere on the vacuum table. These squares with the 1/4 inch holes in them also have a cross machined in each to allow suction to be distributed evenly below the material being machined. These vacuum tables are deliberately produced with the grid groves 0.035 inch deeper then needed. This way the user may remove this thickness from the surface to ensure flatness and to match with their CNC machine following the mounting of the table. The gasket material is a 1/4” diameter and can be used anywhere between the squares. You can create whatever shape is required that can be made around the squares. Overall Size: 48.5" x 24.0" Vacuum Area: Approx. 21.25” x 45.25” Vacuum Table Thickness: 0.80" Mounting Bolts Size: 1/4-20 Individual Square's Size: 1.272” sq. Weight (without packing mat.): 47 Lbs. Not all CNC routers have the same mounting locations so you tell us where you want your mounting locations and vacuum ports. The center line of the mounting/vacuum locations are on a 1.5 inch center to center square grid so you give us your center to center dimensions and we will take it from there. We can customize your table further but this may require further cost with a quote to be drawn up and then we will list your specific request on Ebay for you to purchase. Free shipping for item listed only. We can also include the Vacuum pump or Blower with this quoted system as we sell both the Becker and Gast product line. Users like cabinet and sign makers needing to add MDF spoil-board(s) on top, sucking thru will require a much larger blower which we will be happy to quote. You want to cover your whole 4ft. By 8ft. Machining bed? Well, we will give you a discount if you buy all four sections at the same time. Just ask us to Ebay list it for you. Because these are custom, no returns can be accepted. Included in delivery: One Vacuum table VTZ4824GRID 24 ft. of 1/4” gasket material (12) 1/4” Stop Pins Fittings and Hose Additional items like hardware/hose/valves/manifolds can be added per request of a quote/Ebay listing. Shipping: Due to the fact that this item is made to order, we will need 15 business days before we can ship after design is approved by the customer.
