0.1hz-102.4hz Square Wave Signal Generator Module Display Adjustable Duty Cycle

US $600

, Shenzhen, China
Oct 24th

Open on mobile:
QR code

Store Categories 0.1Hz-102.4Hz Square Wave Signal Generator Module Display Adjustable Duty Cycle Item Description Product Introduction: 1.Power Voltage:5V-24V 2.No Load Current:60MA 3.Output Port:2-channel complementary output(the same freuqncy,opposite phase) 4.Frequency Range:0.1Hz-102.4Hz 5.Frequency Adjusting Step:0.1Hz 6.Duty Cycle Range:1%-99% 7.Duty Cycle Adjusting Step:1% Using Introduction: 1.Ouput Frequency Adjustment:used to adjust output signal frequency 2.Output Signal Duty Cyle Adjustment:used to adjust output signal duty cycle 3.Internal/external Potenitometer Option:when using external potentiometer,plug mini jumper in EXT;when using circuit self-equpped potentiometer,plug mini jumper in INT 4.External Potentiometer Port:to externally install potentiometer 5.Output 1:marking 5V is 5V signal output port,maximum output current is 50MA;marking OC is collector open circuit output port,withstand current is 30V,output low level current is 1500MA 6.Output 2:marking 5V is 5V signal output port,maximum output current is 50MA;marking OC is collector open circuit output port,withstand current is 30V,output low level current is 1500MA 7.Power:DC 5V-24V 8.Power Voltage:when power voltage is 5V,connect with two soldering pads;when power voltage is 7V-24V,disconnect two soldering pads Hot Items Payment Shipping Returns About US Contact Us Payment We Only Accept Paypal on Ebay. For specific requirements, please feel free to contact us. Shipping 1)All orders are processed within 24 hours of payment on business days, and ship to your paypal address. 2)We have many shipping methods, The default one is Hongkong /Singapore Airmail (International shipping), To US customers, we will send the package via E-packet. If you have any need, please contact us. 3)Tax:We will do our best to help you to clear the goods, and the tax depends on each country custom. 4)The product in our store is free shipping but no tracking number. If you wanna have one, you can choose Standard Int’ shipping, we will arrange the shipment with a tracking number. Or you can place a order more than $40 , we will send the items to you with tracking number for free. Returns We will accept returns up to 60 days. 1)If you're not satisfied with the products, please contact us, you can return the products to us in original package and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2)Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. About Us ICs_Processors_Store has been in business for more than 5 years now. We are attended to find popular items at unbeatable prices and pass them on to you the customer. We have been doing this in wholesale for a few years before we decided to bring the deals directly to you! Here is a list of reasons for trusting ICs_Processors_Store as your reliable source of products or business cooperator: 1.Competitive Price 2.High Quality Products 3.Excellent shopping platform 4.Excellent Customer Experience 5.Excellent Team Work With our extremely fast processing and shipping and high superb customer service, we guaranty an excellent buying experience! Contact Us Email: Please contact us through the ebay message system. We will be sure to reply to your message in a timely manner. Our Hours: Monday-Friday 9:00AM - 6:00PM inkfrog terapeak inkFrog Analytics On Oct-24-16 at 08:44:07 PDT, seller added the following information:
