0.2-2100 Khz Measuring And Switching Remote Control Panel P-326-4

US $5,580.00

Lviv, Europe, Ukraine
Jan 29th

Open on mobile:
QR code

High precision Measuring and switching remote control panel P-326-4 analog of Lutron, Advantest, Avtech, HP Agilent, NoiseCom, General Radio, Boonton, Anritsu, Fluke and general Electric, but has the same or better characteristics. This device can be used for wide measurement range. Measuring and switching remote control panel P-326-4 together with measuring generatorP-326-1, and universal level meter P-326-2 are designed for measurement of communication lines,channels and systems paths with frequency division when they are set up, operation and maintenancein frequency range 0.2 kHz - 2100 kHz. With the help of measuring and switching remote control panel measuring the following parameters is provided: - Working attenuation and amplification of symmetric and asymmetric to "ground" four-plus; - Crosstalk attenuation ; - Return loss; - Damping asymmetry. The device is designed for installation and operation in car bodies, can be used in factory and laboratory conditions. Condition: NEW (not used, an old stock). Tested and 100% workable. If necessary, we can provide calibration certificate from Government standardization institute (+145-265usd). Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Please take a look on my other items! If you haven’t found the needed item in my listing, please contact me. I’ll try to help you. Technical characteristics of devices Measuring and switching remote control panel P-326-4 : Device provides operation at temperatures range of -10 ? C to +50 ° C, under conditions of high humidity up to 98% at 35 ° C, as well as frost and dew impact. Operating frequency range of measuring and switching remote control panel P-326-4: a) objects with input and output resistance 600 Ohm - from 0.2 kHz to 150 kHz; b) objects with input and output resistances 135 Ohm, 150 Ohm - from 4 kHz to 620 kHz; c) objects with input and output resistance 75 Ohm - from 60 to 2100 kHz. Frequency response measurements of attenuation inconsistency symmetric, asymmetric objects with input, output resistance - from 0.2 kHz to 1500 kHz. Device measuring and switching remote control panel P-326-4 provides schemes: a) measurement of working and crosstalk symmetric with respect to "ground" objects with nominal resistance 135 Ohm, 150 Ohm, 600 Ohm, working to strengthen symmetric with respect to "ground" objects nominal resistances 150 Ohm, 600 Ohm, and with the help provided in device balancing matching transformers measuring and switching remote control panel P-326-4 allows to measure working attenuation, gain, crosstalk is not symmetric with respect to "ground" objects with nominal resistance 75 Ohm, 135 Ohm, 150 Ohm and 600 Ohm, and working strengthen symmetric " ground " objects with nominal resistance 135 Ohm; b) measuring attenuation of inconsistency symmetric with respect to "ground" objects with nominal resistance 135 Ohm, 150 Ohm, 600 Ohm unbalanced - with a nominal resistance 75 Ohm, 135 Ohm, 150 Ohm, 600 Ohm; c) measuring decay asymmetry of facilities with nominal resistance 135 Ohm, 150 Ohm and 600 Ohm. Device measuring and switching remote control panel P-326-4 measurement limits attenuation measurement inconsistency - from 8dB to 30dB. Asymmetry damping measuring limits in frequency range from 0.2 kHz to 1024 kHz - 45dB. Own crosstalk between input and output circuits of symmetrical schema measuring and switching remote control panel P-326-4 on frequency up to 620 kHz and between input and output unbalanced circuits at frequency up to 2100 kHz - at least 120dB. measuring error of inconsistency damping does not exceed: - ± 1 dB - at frequency up to 150kHz; - ± 1.5 dB - at frequency above 150 kHz up to and including 620kHz; - ± 2dB - at frequencies above 620kHz to 1500kHz inclusive. Device measuring and switching remote control panel P-326-4 measurement error of decay asymmetry is less than ± 2.6 dB. Switching device provides comparing measurements method. Crosstalk between outputs, switched the key - is not less than 40 dB. Device has matching transformers, which provide alignment and balancing: - Symmetric and asymmetric with respect to "ground" four-pluses with nominal resistance 135 Ohm with a symmetrical four-pluses with nominal resistance 150 Ohm; - Symmetric with respect to "ground" with the four-pluses resistance 600 Ohm with symmetric and asymmetric with respect to "ground" four-pluses with nominal resistance 150 Ohm, 135 Ohm; - Symmetric with respect to "ground" two-port with a nominal resistance 150 Ohm, 600 Ohm unbalanced four-resistances 150 Ohm, 600 Ohm. Frequency range of transformers: - 135 Ohm /150 Ohm, 150 Ohm /150 Ohm - from 4 kHz to 620kHz; - 600 Ohm /600 Ohm, 600 Ohm /135 Ohm - from 0.2 kHz to 150 kHz; - 150 Ohm /600 Ohm - from 10 kHz to 150 kHz. Working attenuation transformers: - 600 Ohm /150 Ohm, 150 Ohm /135 Ohm, 150 Ohm /150 Ohm at frequency 50 kHz – is no more than 0.4 dB; - 600 Ohm /600 Ohm, 600 Ohm at Ohm /135 1kHz - less than 0.4 dB. The uneven frequency attenuation characteristics of transformers in relation to damping at medium frequency are less than ± 0.4 dB. The damping of the asymmetry of transformers in the working range of frequency is at least 43dB. Device panel measuring and switching P-326-4 consists of two stores damping: - Fade symmetrical input and output resistances 600 Ohm (M3 Z = 600 Ohm); - Fade symmetrical input and output resistances 150 Ohm with the possibility of using it as box with an asymmetric input and output resistance 75 Ohm (M3 Z = 150 Ohm /75 Ohm). Maximum acceptable input level M3 Z = 150 Ohm /75 Ohm - 10 dB at input M3 Z = 600 Ohm - 20 dB. Maximum attenuation of each box device measuring and switching control P-326-4 - 109.9 dB with possibility to change 0.1 dB. Error on damping constant current does not exceed attenuation at nominal level: From 0 dB to 10 dB, inclusive - ± 0.1 dB; - More than 10dB up to 40dB, inclusive - ± 0.2 dB; - More than 40dB up to 80dB, inclusive - ± 0.4 dB; - More than 80dB up to and including 109.9 dB - ± 1 dB. Input and output box resistance deviation from nominal does not exceed ± 1%. Uneven frequency response of device panel P-326-4-patch measurement does not exceed: - ± 0.1 dB - attenuation for box with input and output resistances 150 Ohm at frequency range 4 kHz, and 620kHz box fade input and output resistance75 Ohm in frequency range 60kHz-2100kHz with attenuation up to 10dB; - ± 0.3 dB - attenuation for box with input and output resistance 600 Ohm at frequency range 0.2 kHz-150 kHz at 0 dB attenuation on up to 80 dB, inclusive, for box damping with input and output resistances 150 Ohm in frequency range 4kHz-620kHz for box fade input and output resistance 75 Ohm in frequency range 60kHz - 2100kHz during fades of 10 dB to 80 dB, inclusive. Additional error device damping box measuring and switching remote P-326-4 on input and output resistances shall not exceed: - ± 0.5% for every 10 ° C from nominal values - in conditions of high and low temperatures, frost and dew; - ± 2% of nominal values - in conditions of high humidity. Device measuring and switching remote control panel P-326-4 additional error does not exceed: - ± 0.05 dB - 10 dB attenuation up to and including; - ± 0.1 dB - for more than 10dB attenuation up to 40dB, inclusive; - ± 0.2 dB - for more than 40 dB attenuation up to 80dB, inclusive; - ± 0.5 dB - for more than 80 dB attenuation for every 10 ° C in conditions of high and low temperatures, and under the action of frost and dew; - ± 0.2 dB - 10 dB attenuation up to and including; - ± 0.4 dB - for more than 10 dB attenuation up to 40dB, inclusive; - ± 0.8 dB attenuation over 40 dB to 80 dB, inclusive; - ± 2dB - for more than 80 dB attenuation under conditions of high humidity. Device measuring and switching remote control panel P-326-4 has 20dB attenuation to input and output resistance 150 Ohm ± 1.5 Ohm to 75 Ohm symmetrical and ± 0.75 Ohm unbalanced with respect to "ground" schemes. Error on decay of working-level direct current does not exceed ± 0.15 dB. Maximum acceptable input level of device measuring and switching control panel P-326-4 is 20dB. Device measuring and switching remote control panel P-326-4 parameters in it, normalized by measuring slots. Device measuring and switching remote control panel P-326-4 dimensions do not exceed 260x500x480mm. Device weight does not exceed 25kg. Warranty 12 months. Delivery term This device is available in stock right now. I can send it at one day after your payment. But due to the fact, that this device is of high precision, it should be calibrated before shipping. I calibrate and test all my devices. Calibration time may take from 1-14 days. (depends on device, usually it takes 3 days.). I can send it at one day after your payment but without any calibration. Please chose. I can supply you such device of fresh years of manufacture 2011-2012, but the price of such device will be approximately 20-40% higher or more. This device also can be named as: P 3264, P3264, P-3264, ? 3264, ?3264, ?-3264 . Photos If necessary we can take photos of a device from various angles. Technical Documentation In case you didn't find in technical specifications for the device all necessary information you are interested in, feel free to contact me. I will look through the technical documentation for the device and I will be happy to consult you. Also I may speak directly with the manufacturer and find out more specific information about this product. If some technical parameters for the device (error, accuracy, measuring range, operating voltage and frequency) do not meet your requirements, please, e-mail me and I will negotiate with the manufacturer whether it is possible to deliver you a device on the desired specifications without a cost increase and in the shortest time. On delivering the device, electric circuit diagrams and all technical documentation for operation, calibration and maintenance will be supplied. Also there will be documents that testify the accuracy and compliance with specifications. In addition, translation of technical documentation into the customer’s language may be discussed. Delivery set On delivering the device will be completely ready for use. There are all necessary cables, adapters, sensors and spare parts as envisaged in technical documentation. Hence, there is no point in purchasing any additional repair & measurement equipment. Warranty Warranty of this item - 12 month. Before sending a device, all devices are checked whether they comply with all technical specifications. Highly qualified metrology engineers carry out the check-up of every instrument at a specialized laboratory and with the help of master gages. If necessary, we can send you photos or video with the check-up process. I ship only fully working devices complying with all parameters. The warranty for this device is 1 year from the date of shipment from my warehouse. Within 1 year term I will provide the repair of the device for free in case of manufacturing defect or when the technical parameters do not comply with technical documentation. You will have to pay only for delivery. When a device is out of order due to your fault (its fall, it is flooded with water, the power supply does not meet the specified technical requirements, input signals exceed the norm, etc.) or there are conspicuous marks of casing opening (broken warranty labels), it is considered a non-warranty repair. Within 1 year term we can advise you for free on the device operation. After-warranty service After warranty termination I can arrange a paid repair and technical maintenance of a device as well as I can sell you all necessary spare parts for repair at minimum prices. I always have them in stock. Packaging Immediately after checking, the device will be wrapped in several layers of strong air-bubble film and placed into a strong cardboard box. Extra cardboard plates will be used for fixation. If necessary, wooden box or pallet may be used. For a more reliable fixation foam can be applied. The whole box will be placed in a waterproof polyethylene bag which will be wound with several layers of packing tape. A special handle will be made for ease of transportation. Thus, I guarantee qualitative and conscientious packing of the device that reduces to minimum the possibility of damage during transportation. Discount (from-10% to -90%) I suggest you a device which is unique in its class and price category with the following specifications: (accuracy, measurement range, error, temperature operating conditions), endurance and durability (military performance, aluminum, stainless steel, titanium or carbolite casing, shock and vibration resistance, high maintainability and reliability), free measuring kit (cables, adapters, load, fuses, etc.), 1year warranty. Unused cheap devices with the same specifications, accuracy and durability do not exist. If you consider the price for this device unreasonably high, and you know the similar equipment at a lower price, please, let me know. I will help you to compare these two models. In case your model (which is cheaper) is the same as the device I suggest or even it is better, then I guarantee to sell you a unit at that cheaper price with additional 10% discount. Shipping details: Please, mind that I ship from Ukraine (Europe, +2), so that the shipping time may differ from your local time. I send goods via AirMailpost. App. delivery time : Europe – 7-15 days; USA, Japan&others – 10-2days (depends on a country). I will ship in 2-3 business days after payment clearance. The goods may also be delivered by the express mail services such as DHL, UPS, FedEx, TNT or EMS. With express delivery you will mostly receive your goods within 3-7 working days. Payment details: I expect payment in 4 days after the auction ends. I accept a PayPal payment as the safest way of payment (preferably). If you do not have a PayPal account you can pay by wire transfer to my credit card. Other variants of payment are acceptable, for example in case of pickup way of shipping, i can accept cash payment. (This will be an official purchase on eBay). Please, tell me if you cannot pay in time, we can always negotiate it. When purchasing a few items, you’ll save on shipping. Return policy: I accept refunds and returns. If there is something wrong with the device, please, inform me within 5 days after receiving it. I will refund your costs or send you the other item, as you wish (after I receive the previous item). Please only serious bidders!

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	P-326-4
MPN	P-326-4
Model	P-326-4
