1 Ea Nos Labinal Toggle Switch W/ Various Applications P/n: 8856k8, Ms21027e231

US $38

Bloomingdale, Illinois, United States
Nov 16th

Open on mobile:
QR code

THIS IS FOR 1 EA TOGGLE SWITCH WITH VARIOUS POSSIBLE APPLICATIONS SUCH AS AEROSPACE, INDUSTRIAL, ROBOTICS, EXPERIMENTAL, MARINE, PROJECTS, ETC. NEW, UNUSED OLD STOCK - 1970'S MFG P/N: 8856K8 ALT. P/N: MS21027E231 NSN: 5930-00-351-6068 MFG: LABINAL SOLD AS-IS. SPECS: ACTUATOR DIAMETER 0.430 INCHES MAXIMUM ACTUATOR HEIGHT 0.983 INCHES NOMINAL ACTUATOR POSITION-ACTION RELATIONSHIP UP POSITION MAINTAINED AND DOWN POSITION MAINTAINED ACTUATOR POSITION-LOCKING RELATIONSHIP UP POSITION NO LOCKING ACTION AND DOWN POSITION NO LOCKING ACTION AND CENTER POSITION LOCKED OUT ACTUATOR STYLE ROUND BODY LENGTH 0.572 INCHES MAXIMUM BODY STYLE BUSHING MOUNT BODY WIDTH 0.556 INCHES MAXIMUM BUSHING LENGTH 0.469 INCHES NOMINAL CASE MATERIAL PLASTIC CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 5.000 AMPERES RESISTIVE DC AND 1.000 AMPERES INDUCTIVE DC AND 2.000 AMPERES RESISTIVE AC AND 1.000 AMPERES INDUCTIVE AC FEATURES PROVIDED ACTUATOR SEAL HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION WATERTIGHT MAXIMUM VOLTAGE RATING IN VOLTS 115.0 AC AND 28.0 DC MOUNTING METHOD THREADED BUSHING MOUNTING SURFACE TO TERMINAL END DISTANCE 0.706 INCHES MAXIMUM NOMINAL THREAD SIZE 0.469 INCHES NONPILE-UP CONTACT ARRANGEMENT 2 POLE, DOUBLE THROW, BOTH POSITIONS MAINTAINED SINGLE SWITCH UNIT INCLOSURE TYPE FULLY INCLOSED PRECIOUS MATERIAL AND LOCATION TERMINAL SURFACES GOLD OVERALL HEIGHT 2.158 INCHES NOMINAL OVERALL LENGTH 0.572 INCHES MAXIMUM OVERALL WIDTH 0.556 INCHES MAXIMUM TEST DATA DOCUMENT 81349-MIL-S-8834 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYPE DATA ON CERTAIN ENVIRONMENTAL AND PERFORMANCE REQUIREMENTS AND TEST CONDITIONS THAT ARE SHOWN AS "TYPICAL", "AVERAGE", "NOMINAL", ETC.). THREAD CLASS 2A THREAD SERIES DESIGNATOR UNS THREAD QUANTITY PER INCH 32 SPECIFICATION/STANDARD DATA 96906-MS21027 GOVERNMENT STANDARD TERMINAL TYPE AND QUANTITY 6 TAB, SOLDER LUG *A1E* MASTER REQUIREMENT CODE (MRC) - A code assigned to each different approved Federal Item Identification Guide (FIIG) requirement. The MRC serves to identify the item characteristic defined by the requirement.
