1 EA NOS LABINAL TOGGLE SWITCH W/ VARIOUS APPLICATIONS P/N: 7660K13, MS25068-24, US $23 – Picture 0
1 EA NOS LABINAL TOGGLE SWITCH W/ VARIOUS APPLICATIONS P/N: 7660K13, MS25068-24, US $23 – Picture 0

1 Ea Nos Labinal Toggle Switch W/ Various Applications P/n: 7660k13, Ms25068-24

US $23

  • Bloomingdale, Illinois, United States
  • Nov 16th
Open on mobile:
QR code
 THIS IS FOR 1 EA TOGGLE SWITCH WITH VARIOUS POSSIBLE APPLICATIONS SUCH AS AEROSPACE, INDUSTRIAL, ROBOTICS, EXPERIMENTAL, MARINE, PROJECTS, ETC.  NEW, UNUSED OLD STOCK MFG P/N:  7660K13 ALT. P/N:  MS25068-24 NSN:  5930-00-577-2523 MFG: LABINAL SOLD AS-IS. SPECS: ACTUATOR HEIGHT 0.690 INCHES NOMINAL ACTUATOR DIAMETER 0.240 INCHES NOMINAL ACTUATOR POSITION-ACTION RELATIONSHIP UP POSITION MAINTAINED AND CENTER POSITION MAINTAINED ACTUATOR STYLE ROUND BODY LENGTH 1.346 INCHES MAXIMUM BODY STYLE BUSHING MOUNT BODY WIDTH 0.430 INCHES MAXIMUM BUSHING LENGTH 0.470 INCHES NOMINAL CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 20.000 AMPERES RESISTIVE DC AND 12.000 AMPERES INDUCTIVE DC AND 5.000 AMPERES LAMP DC AND 20.000 AMPERES RESISTIVE AC AND 15.000 AMPERES INDUCTIVE AC AND 4.000 AMPERES LAMP AC FEATURES PROVIDED ACTUATOR SEAL HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION SUBMERSIBLE III END ITEM IDENTIFICATION MISSILE MINUTEMAN LGM-30 MAXIMUM VOLTAGE RATING IN VOLTS 115.0 AC AND 28.0 DC MOUNTING METHOD THREADED BUSHING MOUNTING SURFACE TO TERMINAL END DISTANCE 1.390 INCHES MAXIMUM NOMINAL THREAD SIZE 0.469 INCHES NONPILE-UP CONTACT ARRANGEMENT 4 POLE, SINGLE THROW, BOTH POSITIONS MAINTAINED SINGLE SWITCH UNIT INCLOSURE TYPE FULLY INCLOSED OVERALL HEIGHT 2.550 INCHES NOMINAL OVERALL LENGTH 1.346 INCHES MAXIMUM OVERALL WIDTH 1.680 INCHES MAXIMUM THREAD SERIES DESIGNATOR UNS THREAD QUANTITY PER INCH 32 SPECIFICATION/STANDARD DATA 96906-MS25068 GOVERNMENT STANDARD TERMINAL TYPE AND QUANTITY 8 TAB W/SCREW TEST DATA DOCUMENT 81349-MIL-DTL-83731 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYPE DATA ON CERTAIN ENVIRONMENTAL AND PERFORMANCE REQUIREMENTS AND TEST CONDITIONS THAT ARE SHOWN AS "TYPICAL", "AVERAGE", "NOMINAL", ETC.).                                            *A1E* MASTER REQUIREMENT CODE (MRC) - A code assigned to each  different approved Federal Item Identification Guide (FIIG) requirement.  The MRC serves to identify the item  characteristic defined by the requirement.
