1 pc AD9958 Two channels DDS signal generator module V2 version, US $95.00 – Picture 0

1 pc AD9958 Two channels DDS signal generator module V2 version, US $95.00 – Picture 1

1 pc AD9958 Two channels DDS signal generator module V2 version, US $95.00 – Picture 2

1 pc AD9958 Two channels DDS signal generator module V2 version, US $95.00 – Picture 3

1 pc AD9958 Two channels DDS signal generator module V2 version, US $95.00 – Picture 4

1 Pc Ad9958 Two Channels Dds Signal Generator Module V2 Version

US $95.00

shenzhen, China
Jan 29th

Open on mobile:
QR code

1 PC AD9958 DDS signal generator module V2 version Description AD9958 DDS signal generator module V2 version First, the module features: 1, AD9958: 2-channel, 500MSPS, the highest 200M sine wave output; 2,2 channel independent of frequency, amplitude and phase adjustable; 3,32-bit accumulator, frequency resolution better than 0.12HZ, dashboard control precision 1Hz; 4,14-bit phase register, phase resolution 0.022 degrees, 1 degree phase accuracy dashboard controls; 5,10-bit amplitude register, fine adjustable amplitude 1024; 6,2-order, fourth-order, 8 bands, 16 bands, ASK, PSK, FSK modulation powerful features; 7, linear frequency, amplitude and phase sweep function; 8, independent programmable DAC output current; 9, high-speed SPI communication; 10, original PC control software, control panels using 32 MCU: STM32F103, USB2.0 and serial interfaces; PC software and USB drive support any version of the Windows operating system; 11, modular design, can be freely combined upper and lower, and you can use your own control module; 12, provided the underlying AD9958 driver source code, very easy to use and portable to any MCU: void AD9958_CSR(unsigned char data); void AD9958_FR1(unsigned long data); void AD9958_FR2(unsigned int data); void AD9958_CFR(unsigned long data); void AD9958_CFTW0(unsigned long data); void AD9958_CPOW0(unsigned int data); void AD9958_ACR(unsigned long data); void AD9958_LSRR(unsigned int data); void AD9958_RDW(unsigned long data); void AD9958_FDW(unsigned long data); void AD9958_CH_Word(unsigned long data,unsigned char index); void AD9958_Init(void); Second, the application module: 1, the local oscillator; 2, the test equipment; 3, the synchronous clock, the high-frequency signal source; 4, AD9958 learning modules; Third, the module performance parameters: 1, the control board power supply: USB communication: USB power supply to the control panel, an external 5V power supply to the AD9958; RS232 communication: external 5V power supply to the AD9958 and control panel; 2, using high-speed operational amplifier coupled to the output, after impedance matching, post-200M filter; 3, the output frequency 0 --- 200M, 1HZ resolution; 4, the output amplitude 0-2VPP @ 1M high impedance, 0--1VPP @ 50 in Europe, Flat rate: 0-100M @ 0.4dB 100M --- 150M @ 1dB flatness The magnitude of the amplitude can be achieved by 1024 PC software fine adjustable; 5, independent of the phase adjustment, a degree of fine phase resolution can be achieved and so the signal generated IQ. Four, comprising: 1, 1PC AD9958 module 2, 1PC control module 3, 1PC USB line 4, 1PC cable Payment Payment : We accept paypal Credit card payments must be made through PayPal. We recommend you to sign for a PayPal account before bidding. We will Not take responsible on Customs duty if any Shipping time : Shipping time : If you haven't get your parcel within the expected date,Pls contact with us directly.We can ensure solve it for you .Pls trust us .We need your support. Thanks .Yours Sincerely. Country Shipping Time Refund or Resend 80% 12% 5% United States United Kingdom Australia /Canada 10-20 working days 25 working days 27 working days >27 working days Singapore Other Asia country 15-25 working days 28 working days 32 working days >32 working days Germany /France Austria /Netherland Poland 20-30 working days 33 working days 36 working days >36 working days Spain Russia 25-35 working days 37 working days 40 working days >40 working days Others 25-35 working days 37 working days 40 working days >40 working days Feedback Feedback : We would appreciate receiving your 5 stars positive feedback.If there's any dissatisfaction with your parcel ,pls contact with us before you leave the feedback .We can solve it for your perfectly.Thanks for your understanding and help. Return Policy 1. All items are checked and packed in good condition before dispatch. 2. If you find any defect in our items, please contact us within 14 days of receipt item. 3. Return items must not be used. 4. Buyer is responsible for all return shipping charges. We will return all your money except the shipping and handling fees or make exchange for you after we receive your return items. Please do not ship the item back to us without our confirmation. Thanks Contact us SHIPPING TERMS: Our work time is during 8:00 am -5:30 pm ,from Monday to Friday (GMT+8 ).We will post your order within 24 hours (Except some special orders ,such as the handmade case). Maybe we are out of office during the weekend, so pls wait for our reply patiently. We will reply all your problems as quickly as we can. Thanks for your understanding. Engineered for professional eBay sellers!
