10 Pcs/lot Ic Lpc2368fbd100, Single-chip 16-bit/32-bit Microcontrollers

US $66.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Single-chip 16-bit/32-bit microcontrollers; up to 512 kB flash with ISP/IAP, Ethernet, USB 2.0, CAN, and 10-bit ADC/DAC 1. General description The LPC2364/66/68 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S CPU with real-time emulation that combines the microcontroller with up to 512 kB of embedded high-speed flash memory. A 128-bit wide memory interface and a unique accelerator architecture enable 32-bit code execution at the maximum clock rate. For critical performance in interrupt service routines and DSP algorithms, this increases performance up to 30 % over Thumb mode. For critical code size applications, the alternative 16-bit Thumb mode reduces code by more than 30 % with minimal performance penalty. The LPC2364/66/68 are ideal for multi-purpose serial communication applications. They incorporate a 10/100 Ethernet Media Access Controller (MAC), USB full speed device with 4 kB Endpoint RAM, four UARTs, two CAN channels, an SPI interface, two Synchronous Serial Ports (SSP), three I2C interfaces, and an I2S interface. This blend of serial communications interfaces combined with an on-chip 4 MHz internal oscillator, SRAM of up to 32 kB, 16 kB SRAM for Ethernet, 8 kB SRAM for USB and general purpose use, together with 2 kB battery powered SRAM make these devices very well suited for communication gateways and protocol converters. Various 32-bit timers, an improved 10-bit ADC, 10-bit DAC, one PWM unit, a CAN control unit, and up to 70 fast GPIO lines with up to 12 edge or level sensitive external interrupt pins make these microcontrollers particularly suitable for industrial control and medical systems. 2. Features oЂ‚„ ARM7TDMI-S processor, running at up to 72 MHz. oЂ‚„ Up to 512 kB on-chip Flash Program Memory with In-System Programming (ISP) and In-Application Programming (IAP) capabilities. Flash program memory is on the ARM local bus for high performance CPU access. oЂ‚„ 8/32 kB of SRAM on the ARM local bus for high performance CPU access. oЂ‚„ 16 kB SRAM for Ethernet interface. Can also be used as general purpose SRAM. oЂ‚„ 8 kB SRAM for general purpose DMA use also accessible by the USB. oЂ‚„ Dual AHB system that provides for simultaneous Ethernet DMA, USB DMA, and program execution from on-chip Flash with no contention between those functions. A bus bridge allows the Ethernet DMA to access the other AHB subsystem. oЂ‚„ Advanced Vectored Interrupt Controller, supporting up to 32 vectored interrupts. oЂ‚„ General Purpose AHB DMA controller (GPDMA) that can be used with the SSP serial interfaces, the I2S port, and the SD/MMC card port, as well as for memory-to-memory transfers. oЂ‚„ Serial Interfaces:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NXP
IC Package	LQFP100_14X14X05P
Model	GoJGo.com-10533
Category	MCU
MPN	LPC2368FBD100
