10" Precision Tilting Rotary Table

US $9800

  • Norcross, Georgia, United States
  • Jun 3rd
Part No. 535 - 5250  The best quality among others.             Truck shipping only.  We can offer you the low shipping cost, please contact us if needed.  The local pickup is available. Shipping weight: 205 lbs. The dimension of the package: 22 x 17 x 13" Specifications: Diameter of table: 10" ( 250 mm ) Center bore: morse taper # 3 Diameter and depth of center hole: 1.18 x 0.24" Width of locating key: 0.551" Tilting angle of table: 0 - 90 degree Indexing accuracy: 60" Diameter of center hole and depth : 1.5748" x 0.3937" Width of T slot: 0.5511" 6 T slots Transmission ratio of worm gear: 1:90 Graduation of table: 360 degree Tilting angle: 0 - 90 degree. Readout of hand wheel: 1' Minimum reading of vernier: 10" Minimum reading of the tilting vernier: 2' Indexing accuracy: 60" Maximum working load: 440 lbs ( horizontally ) Maximum working load: 220 lbs ( vertically ) Surface to center slot squareness 0.0003" Taper center bore concentricity TIR 0.0005" Surface to base parallelism 0.0008" Surface to angle face squareness 0.0004" Cylinder center bore concentricity TIR 0.001" The Dividing Plate, The Chuck and Adapter are optional parts. You may check the other listings.   Warranty: one year.   Contact us for shipping cost @ topqc789@aol.com or 678-232-7327
