10 Rpm (rotisserie) Gear Motor 115v 230v Reversible Variable Speed Brushless Dc

US $190.00

Walnut, California, United States
Feb 12th

Open on mobile:
QR code

10 RPM (Rotisserie) Gear Motor 115V 230V Reversible Variable Speed Due to its low speed property and its variable speed feature. This motor is ideal for a low speed rotisserie application. For the rotisserie application, be sure to set up bearings specifically to hold up the weight of the meat so the motor is only to rotate the meat with minimum axial and radial loads. Also, flexible couplings are highly recommended for a direct-drive set up. Due to the nature of a BBQ rotisserie's high temperature environment, make sure the motor is placed far enough from the heat to prevent failures of the motor's mechanical or electrical components. A fire wall should be considered to protect the motor. This motor was tested with a 50kg (110lb) of weight with its variable speed feature at ease. The 50kg (110lb) weight is to simulate a 50kg (110lb) hog/pig that is traditionally roasted with an outdoor BBQ rotisserie set up. This is a compact, single-phase, 115v ac to 230v ac input, permanent magnet, BRUSHLESS gear motor with reversible, on/off, speed adjustable controls. Speed range varies depending on the shaft load. Motor's maximum speed is 10 RPM. Rotation is reversible by a signal wire. This combination will be described in two parts: brushless dc gear motor and power adapter. Brushless 12VDC Gear Motor: 24 N-m (17.7 ft-lb) torque at 10 RPM. Permanent magnet rotor. 60mm x 60mm square motor with 56mm diameter gear box. 4 M5 threaded holes located at front for face mounting. Motor length is 6.75 inch (171mm) long and its controller is integrated as part of the motor. Shaft is 12mm in diameter with a flat and is 1 inch (25.4mm) long. The control line, which contains speed adjustment (with a pot soldered already), reversing signal wire, on/off signal wire, and signal ground wire, is 14 inch (356mm)long. Connector line that is to connect to the power adapter is 14 inch (356mm) long. Motor control is very simple. To turn the motor on, simply disconnect the on/off (blue) wire to signal ground (black) wire. A typical practice is to introduce a switch between the on/off wire and the ground wire. To reverse the rotation of the motor, simply connect the reverse (white) wire to the same ground wire and the motor will reverse its rotation. PLEASE BE SURE THAT THE MOTOR IS AT FULL STOP BEFORE REVERSING. To vary the speed, simply turn the potentiometer. Power Adapter: The power cord is 5 ft(152 cm) long and has a standard plug ready to plug into a standard appliance outlet. The adapter is able to universally accept 115v ac or 230v ac. Connector line that is to connect to the motor is 3 ft (91 cm) long. Adapter's dimensions are 2.5 in(64mm) width by4.75in(121mm) length by 1.75in(44mm) depth.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	WONDERMOTOR
Product+Type	Gearmotor
Model	PN00211
Motor+Controls+Type	Speed+Controls
MPN	PN00211
Drive+%26+Amplifier+Type	DC+Motor+Controller
Product Type	Motor Controls
Motor+Part+Type	Permanent+Magnet
Manufacturer	Wondermotor
