10mhz Arbitrary Waveform Dual Channel Dds Function Signal Generator + 2.4"lcd

US $128.00

Registered Air Mail ( Worldwide ), China
Jan 29th

Open on mobile:
QR code

10MHz DDS Function Signal Generator Module Arbitrary Wave TTL Output with Sweep Fuction Features: 1 Adopting direct digital synthesis (DDS) technology, FPGA design, and ultra-low power consumption; 2 With portable aluminum alloyed shell, sole DC 5V powered adapter, easy to carry; 3 With a 2.4-inch TFT color LCD, variable function soft keys and a rotary encoder, greatly enhances the usability of the instrument; 4 Perfectly symmetrical two channels can be synchronized to work, and the phase adjustable; 5 Two or multi-machines can be achieved multi-machines synchronous by TTL_IO port; 6 Various basic function waveforms of sine, triangle, square, saw tooth, and pulse (duty adjustable); 7 The minimum output signal frequency to 10?Hz; 8 With 100 sets (M00~M99) parameter storage locations, data of M00 can be loaded as power on; 9 With 15 sets arbitrary waveform storage locations for users self-defining, memory depth of each set is 1024*10 bits; 10 Amplitude up to 20Vp-p as frequency ?15MHz; amplitude up to 15Vp-p as frequency >15MHz; 11 Minimum frequency resolution reaches 10?Hz, minimum amplitude resolution to 10mV; 12 With DC offset function (-100%~+100%); 13 With FSK function, hop frequency, carrier frequency and FSK rate can be set freely; 14 Three trigger modes, manual trigger, internal CH2 trigger, external trigger, an arbitrary burst of 1~1048575 can be outputted; 15 If the setting is +100%, any CMOS digital signal of 0~10V can be outputted; 16 Duty adjustment of pulse wave is accurate to 0.1%. 17 The burst function can control the output pulses from 1 to 1048575. 18 Frequency sweep, amplitude sweep and duty sweep with an arbitrary start and end point. 19 With functions of frequency measurement, period measurement, positive and negative pulse width measurement, duty cycle measurement and counting. 20 All parameters can be calibrated by internal program. 21 Powerful communication functions and the completely open communication protocol, which makes it very simple to the secondary development. 22 After in connection with the PC, the PC can be used to control the instrument and arbitrary waveforms edited on the PC can be download to the instrument to output. Technical data MHS2300A-05M/10M/20M Main output Frequency range Sine Normal: MHS2300A-05M:0Hz~5MHz; MHS2300A-10M:0Hz~10MHz; MHS2300A-20M:0Hz~20MHz? Ultra-low frequency :0~600Hz Square 0Hz~5MHz Triangle 0Hz~5MHz Saw tooth 0Hz~5MHz Arbitrary 0Hz~5MHz CMOS 0Hz~5MHz Output modulation Frequency sweep? amplitude sweep?duty cycle sweep?FSK?burst Waveform Sine?Square?triangle?pulse?ramp?CMOS?Arbitrary Waveform length 1024 points Sampling rate 200MSa/s Wave accuracy 10bits Frequency resolution 10mHz(Normal),10?Hz( Ultra-low frequency ) Frequency error ±5x10-6 Frequency stability ±1x10-6 Amplitude range (peak to peak) MHS2300A-05M : 10mVp-p~20Vp-p; MHS2300A-10M : 10mVp-p~20Vp-p; MHS2300A-20M : 10mVp-p~20Vp-p(frequency?15MHz), 10mVp-p~15Vp-p(frequency>15MHz) Output impedance 50?±10% Amplitude resolution 10mVp-p Amplitude stability ±0.5%(per 5 hours) Amplitude error ± 1%+10mV(frequency 1KHz., 20Vp-p) Offset range -100%~+100%(the ratio of offset voltage to signal amplitude) Offset resolution 1% Phase range 0~360° Phase resolution 1° Sine Harmonic distortion 40dBc(<1MHz) ,35dBc(1MHz~20MHz) Distortion factor <0.8%(20Hz~20KHz) Square Rise or fall time
