10mhz Dds Function Signal Generator Module Sine Square Triangle Ramp Waveform

US $28.49

guagnzhou, China
Jul 31st

Open on mobile:
QR code

DDS Function / Arbitrary Waveform Generator uses direct digital synthesis technique (DDS), FPGA design, interior prefabricated 7 kinds of commonly used waveform while users can also edit the output 8-bit, 256 points user-defined arbitrary waveforms ; its easy to use , the signal high stability , low distortion , with 1 watt power output, wideband frequency measurement and counter functions. The output signal amplitude and DC offset can be adjusted Waveforms: sine, square, triangle , ramp, user-defined waveform ( Arb ) , commonly used pulse, noise, electrocardiogram waveforms. Main technology data signal outpu Output waveform Sine, square wave (variable duty cycle), triangle wave, sawtooth, Arbitrary waveforms, commonly used pulse, noise, ECG, AM, FM and other waveforms. Output amplitude 0.5-8Vp-p (no load) Output impedance 10 ohms ± 10% DC bias ± 3V Frequency Range 0.01Hz ~ 50kHz Frequency resolution 0.01Hz(10mHz) Frequency Accuracy ±510-6 Frequency Stability ±210-6/3hours Sine wave distortion 0.8% (Reference frequency 1kHz) Triangle wave linearity 98% (0.01Hz~10kHz) Square wave an increase of Fall Time 100ns Square wave duty cycle range 1%~99% COUNTER Counter function Counting range 0-65535 Measurement frequency range 1Hz~20MHz Input amplitude 0.5Vp-p~20Vp-p Other Display LCD1602 LCD display in English Storage and Recall function M0-M9 (M0: default transferred) Size 83mm (length) 60 mm (width) x 24mm (height) Buzzer function Can be programmed to turn on or off Production Process Surface mount technology, LSI High reliability and long service life Operating Characteristics All key operations, continuous adjustment knob Environmental conditions Temperature0~40 Humidity80% Package included : 1 x DDS Function Signal Generator Module Custom Arbitrary Waveform Sine Triangle 1 x 5V Power supply On Jul-30-21 at 20:41:07 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Country/Region of Manufacture	China
MPN	Does Not Apply
Signal Generator Type	Function Generator
UPC	Does Not Apply
ISBN	Does Not Apply
EAN	Does Not Apply
