10pcsxdc-dc Step Down Converter Led Driver Module Charger 7-35v To 1.25-25v 0-3a

US $63.70

Guang Zhou, China
Jan 29th

Open on mobile:
QR code

10PCSxDC Buck Step Down Converter Constant Current Voltage Power Supply Input: 7-35V, Output: 1.25-25V 0-3A DC Charger #090464 Product Description Feature: Module Properties: non-isolated Buck constant current, constant voltage module (CC CV) charging module Scope: High-power constant current LED driver. Battery charger (including ferroelectric), 4V, 6V, 12V, 14V, 24V battery charging, nickel-cadmium nickel-metal hydride batteries (battery) charger, solar panels, wind generators. Solar Panel, Wind generator voltage regulator, Car Power Supply. Input voltage: 7-35V Output voltage: 1.25-30V Output Current: Max 3A ( If more than 15W, please install the heat sink, this item do not include heat sink) Constant current range :0-3A (adjustable) Minimum voltage pressure: 2V Output power: natural cooling 15W Conversion efficiency: 85% (the higher the output voltage, the higher the efficiency Operating Temperature: Industrial (-40°c to +85°c) (if ambient temperature exceeds 40 °c, please lower power use, or to enhance heat dissipation) Full load temperature rise: 45°c No-load Current: typical 10mA (12V to 4.2V) Load Regulation: ± 1% Voltage Regulation: ± 0.5% Current precision and temperature: Actual Testing, Temperature changes from 20 degrees To 100 degrees, Constant current value change Less than 1% (constant current value 1A) Dynamic response speed: 5% 200uS Potentiometer adjustment direction:Clockwise (increase),Counterclockwise (decrease) Indicator LED: Charging LED Red, Full Charge LED Green Output Short-circuit Protection:YES Input Reverse Polarity Protection:YES Output Prevent Countercurrent: YES Battery Charging method: 1. Make sure the recharge battery float voltage and charge current, input voltage of the module. 2. adjust constant voltage regulator, the output voltage about 3V. 3. With a multimeter ( to 10A) Measuring output Short-circuit current, Also adjust the constant regulator allows Output current reaches a predetermined charge current value; 4. Adjust Constant regulator allows Output voltage reaches the float voltage; 5. connected to the battery, try charging. (1,2,3,4 step input connect power, output do not connect battery.) LED constant current driver Usage: 1. Make sure LED current and the maximum operating voltage; 2. adjust constant voltage regulator, the output voltage about 3V. 3. With a multimeter ( to 10A) Measuring output Short-circuit current, Also adjust the constant regulator allows Output current reaches a predetermined LED working current value; 4. Adjust Constant regulator allows Output voltage Reach LED maximum working voltage; 5. Connected to the LED, test. (1,2,3,4 take steps input connect power, output do not connected LED.) Package Includes: 10x DC-DC Converter Payment Method We accept only Paypal for both domestic and international. We will ship to the shown address on you PAYPAL Payment notice,Please confirm your shipping address in the PayPal Account. If buyer want to delay the payment because of financial problem, please contact me by the ebay message within 3 days. Shipping Detail Ship by Post Air-mail within 3 working days after full payment is received. The shipment usually takes 15-45 business days to Worldwide. We also provide international Expressed delivery such as EMS, DHL and UPS,extra shipping fees is needed. The shipping time may vary, depends on receiver's location. Feedback Policy We will leave positive feedback to buyer as soon as buyer pays for the item. Leaving Negative feedback or Netural Feedback is never a good way to resolve problem .We hightly appreciate that you can contact with us before you leaving Negative feedback or Neutral feedback .We will offer help to resolve your problems as fast as possible. Customer Service Work Time If you have any questions,Please contact with us via eBay message or our customer service e-mail . please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 11:00 - 20:00 and Saturdays 11:00 – 15:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) Engineered for professional eBay sellers! On Dec-19-14 at 14:53:13 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Input voltage	7-35V
Voltage Regulation	± 0.5%
Output voltage	1.25-30V
Dynamic response speed	5% 200uS
Constant current range	0-3A (adjustable)
Potentiometer adjustment direction	Clockwise (increase),Counterclockwise (decrease)
Minimum voltage pressure	2V
Indicator LED	Charging LED Red, Full Charge LED Green
Output power	natural cooling 15W
Output Short-circuit Protection	YES
Full load temperature rise	45°c
Input Reverse Polarity Protection	YES
No-load Current	typical 10mA (12V to 4.2V)
Output Prevent Countercurrent	YES
Load Regulation	± 1%
