10x(icstation Digital 2 Channel Pwm Square Wave Pulse Signal Generator

US $41.14

Pennsylvania, United States
Jul 3rd

Open on mobile:
QR code

10X(Icstation Digital 2 Channel PWM Square Wave Pulse Signal Generator 10X(Digital square waveform generator module support 1Hz-150KHz frequency and 0%-100% duty cycle adjusting independently through the on-board momentary push button. Dual channel fequency signal and duty cycle complementary output, easier to control. DC5-30V wide voltage input(support micro-USB 5V input),3 digit LED display the parameter easy to read, serial communication interface easy to connect and controlled by MCU. Used as square wave source for instrument testing,driving the stepper motor, PWM control the motor speed / LED light brightness. Accuracy: 2% Output Current: 8-30mA Output Amplitude: 5V V-PP (default, changed by external power supply) Display Instructions: There are 3 display range: XXXX- more than the unit is 1Hz, range is 1Hz-999Hz XX.X- more than the unit is 0.1KHz,range is 0.1KHz-99.9KHz X.X.X.- more than the unit is 1KHz, range is 1KHz-150KHz e.g.:100- more than 100Hz;54.1- more than 54.1KHz;1.2.4.- more than 12KHz Setting Instructions: Short press"Set" to interchange display the 4 values(FR1:PWM1 frequency;dU1:PWM1 duty cycle;FR2:PWM2 frequency;dU2:PWM2 duty cycle) Press"Up" and "Down" to set the current value Serial Control: Baud Rage: 9600pbs; Date Bit: 8; Stop Bit: 1; Set the PWM frequency: "S1FXXXT": set the PWM1 frequency as XXX HZ(0001-999); "S1FXX.XT": set the PWM1 frequency as XXX KHZ(00.1-99.9); "S1FX.X.X.T": set the PWM1 frequency as XXX KHZ(0.0.1.-1.5.0.)(S1- more than PWM1; s2- more than PWM2; F- more than frequency; D- more than duty cycle; T- more than Stop bit) Set the PWM duty cycle: "S1DXXXT": set the PWM1 duty cycle as XXX(001-100); "S2DXXXT": set the PWM2 duty cycle as XXX(001-100) 3.DOWN: set successful; FALL: set fail. Colour: blue Material: PCB Size: 41x29 mm Package Contents: 2 * Digital 2 Chan)
