1500w 3 Axis Cnc 6040 Router Engraver 3d Carving Engraving Machine+controller Eu

US $959.99

Basel, Switzerland
Jul 2nd

Open on mobile:
QR code

CNC engraving machine parameters: X, Y, Z Working Area: 600(Y)*390X*120(Z)mm Outside dimension: 865*680*570mmL*W*H Table size: 770Y*490Xmm Lathe structure: 6061/6063 Aluminium alloy Max. Feeding height: 100mm Drive unit: X axis---1605 Ball Screws Y axis---1605 Ball Screws Z axis---1204 Ball Screws Sliding unit: X axis---High intensity Chromeplate shaft Y axis---High intensity Chromeplate shaft Z axis---High intensity Chromeplate shaft Stepping motor: 57 two-phase 3A 150N.cm Spindle motor: tips1. The spindle motor must connect with the VFD. 2. It cannot directly connect with the supply voltage (AC220V). 3. Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Outside dimension Store category Sign Up Now ! You may also like 1500W 3 Axis CNC 6040 Router Engraver 3D Carving Engraving Machine+Controller EU Product Description ATTENTION : This machine comes with EU plug , please prepare an UK adapter plug cable yourself IF YOU HAVE ANY QUESTION, PLZ CONTACT US! SKU: 3AIX60401+3AIX60403+3AIX60404+TS007 Attention: This machine needs to connect to a computer through its controller box with a parrallel cable (both included). It is not recommended to connect to a notebook through a parrallel port as the power saving features tend to interrupt the data flow. It is also not recommended to connect to a computers with 64 bit versions of Windows due to problems with the Parrallel port driver. These issues are detailed and fully explained on the Software website. Description: suitable for PCB, wood, Plexiglass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper, 1. This CNC 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. 2. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. and soft metal. like aluminum, copper and silver to engrave them into 3D/2D works etc. 3. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 4.The mini CNC router Frame is movable. The machine can connect with computer as other external device such as printer, scanner... 5. With the assist of the CNC ROUTER 6040T, your design idea will be real-time display. CNC Engraving Machine Parameters: X, Y, Z Working Area: 600(Y)*390X*120(Z)mm Outside dimension: 865*680*570mmL*W*H Table size: 770Y*490Xmm Lathe structure: 6061/6063 Aluminium alloy Max. Feeding height: ≤100mm Drive unit: X axis---1605 Ball Screws Y axis---1605 Ball Screws Z axis---1204 Ball Screws Sliding unit: X axis---High intensity Chromeplate shaft Y axis---High intensity Chromeplate shaft Z axis---High intensity Chromeplate shaft Stepping motor: 57 two-phase 3A 150N.cm Spindle motor: tips: 1. The spindle motor must connect with the VFD. 2. It cannot directly connect with the supply voltage (AC220V). 3. Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Outside dimension: 80*188 mm Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC220v 50hz, 5A, 1.5KW VFD Spindle motor: 1.5 KW water cooled Spindle speed: 24000 rpm Max working frequency: 400Hz Principal axis collet:ER11colletStandard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way: Lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through parallel connection with computer Software environment: Windows XP/win7, 32bits system Working Speed: 50-1500mm / min (different material with different speed settings) Maximum Idle speed: 0-1500mm/min Friendly reminder: The engraver will come with softwareFree Version If you followed the installation tips offered by us, it works like full version. installation tips: The software perform better on the 32bites system computer. Please close the firewall and antivirus software on the computer before DOWNLOADING AND installing the software.(This is very important) Otherwise, the antivirus will regard the cnc software as virus and stop the installation. PS: Please don't update the software when installed, then it will not need the license Numbers. Control box parameters: Operating Voltage: AC220V, 50hz Control unit: Toroidal transformer + PWM power supply module + TB6560stepping motor drive Computer connection: Parallel port Command code: G code Acceptable software: Protection: Emergency stop button Feature: 1. The NEW 1.5KW water-cooled VFD is available operating for long time,which can reinforced the processing abilty of the machine and can be used toprocess aluminum alloy and hard wood. 2. water cooling spindle works more stable and durable. 3. High quality accurate ball Screws drive make the engrving more precision.Anti-blackflash,high precision,long life circle. 4. Software CompatabilityType3/ArtCAMParameter How to Use 1. Assembling and locating the CNC machine on steady desk well. 2. Make sure that your computer has a 25pin parallel port output. 3. Place the contral box in a ventilated dry place where there is no dust, no moisture 4. Connecting the control box with the CNC machine and you computer and make sure the plug will not come off. 5. Correctly connect the machine with the controller. Don't suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Otherwise, it will damage the driver of the controller. 6. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. 7. Installing a CNC control software and Drive such as the on your computer. 8. Fllowing our manual or guideline to set uo the software. 9. Before turn on the machine, please check all the cable and water-cooling system to make sure they are working fine. 10. You can enjoy making you dream with using our CNC machine now. Descrizione: Adatto per PCB, legno, plexiglass, PVC, cristallo acrilico, resina, plastica, guarnizioni, materiali compositi, di MDF, alluminio, rame, 1. questa macchina CNC 6040T è adatta per industria, tecnologia di ricerca, pubblicità design. Creazione di arti, insegnamento, studente progetto e hobby fini. 2. può funzionare con vari materiali (metallici e non metallici), come: legno, pmma o l'altra plastica. Bordo di MDF, legno nativo, PVC, acrilico, legno, compensato bordo composito. e metallo morbido. come l'alluminio, rame e argento per incidere loro in 3D/2D opere ecc. span style="font-family: 'Times New Roman'; font-size: 14pt;">3. può essere utilizzato per l'incisione: targhette di segni, PCB, di pubblicità, distintivi, guarnizioni, piastra, per bronzare. lega di alluminio, lastre acriliche, ABS resina doppio piatto di colore, bordo di schiumatura del PVC, lastre di indentazione, segni. costruzione modelli, quadri portastrumenti, prodotti in legno, ecc. 4. mini CNC router telaio è mobile. La macchina può connettersi con il computer come altro dispositivo esterno come stampante, scanner... 5. con l'assist di CNC ROUTER 6040T, vostra idea di design sarà visualizzazione in tempo reale. Parametri della macchina CNC incisione: Area di lavoro X, Y, Z: 600 (Y) * 390 (X) * 120 (Z) mm Dimensione esterna: 865*680*570mm(L*W*H) Formato della tabella: 770 (Y) * 490 (X) mm Tornio di struttura: lega di alluminio 6061/6063 Max altezza d'alimentazione: ≤100mm DRIVE UNIT: Viti a sfere X Axis--1605 Viti a sfere Y asse-1605 Viti a sfere Z asse-1204 Unità di scorrimento: Asse-X - albero di Chromeplate ad alta intensità Albero Y asse--ad alta intensità di Chromeplate Asse-Z - asse di Chromeplate ad alta intensità Motore passo-passo: 57 3A 150N.cm a due fasi Motore mandrino: (suggerimenti: 1.) Il motore mandrino deve collegarsi con il VFD. 2. non è possibile connettersi direttamente con la tensione di alimentazione (AC220V). 3. si prega di non cambiare l'impostazione di dati di VFD se non siete tecnici professionisti, o potrebbe danneggiare il motore del mandrino. Dimensione esterna: 80*188 mm Materiale: 304 serpentina in acciaio inox, rame, pressione cast alluminio tubo acqua giacca Potenza attuale, volt,: AC220 / 50Hz, 5A, 1.5 KW VFD Velocità del mandrino: 24000 giri/min Massima frequenza di lavoro: 400 Hz Asse principale hebel: ER11collet, configurazione standard: 6mm Modello di dado: ER11-A Raffreddamento: Acqua di raffreddamento Modalità di velocità: regolando il VFD uscita tensione e frequenza da 0-24000 giri/min Lubrificazione modo: lubrificato con grasso ad alta Ripetibilità: 0,05 mm Precisione mandrino: radiale battere le acuità 0,03 mm Istruzioni di scultura: codice G / TAB file / file nc / file NCC Interfaccia di comunicazione: attraverso il collegamento in parallelo con il computer Ambiente software: Windows XP/Win7 Velocità massima: 0-4000 mm/min Intaglio di velocità: 0-2500 mm/min(different materials differ) Ricordo amichevole: L'incisore arriverà con software (versione gratuita Se avete seguito i suggerimenti di installazione offerti dagli Stati Uniti, funziona come versione completa). Consigli per l'installazione: Il software di eseguire meglio il computer del sistema di 32bites. Si prega di chiudere il firewall e software antivirus nel computer prima di scaricare ed installare il software. (Questo è molto importante) In caso contrario, l'antivirus sarà considerare il software cnc come virus e interrompere l'installazione. PS: Si prega di non aggiornare il software installato, quindi non avrà bisogno i numeri di licenza. Parametro di casella di controllo: Tensione di funzionamento: AC220V Unità di controllo: PWM + trasformatore toroidale di alimentazione moduli + TB6560stepping motor drive Connessione computer: porta parallela Codice comando: codice G Software di accettabile: Protezione: Pulsante di arresto d'emergenza Caratteristica: 1. il nuovo 1.5 KW è disponibile di funzionamento per lungo tempo l'elaborazione di rinforzo VFD raffreddato ad acqua, che può abilty della macchina e può essere usato aprocesso in lega di alluminio e legno duro. 2. acqua di raffreddamento mandrino funziona più stabile e durevole. 3. alta qualità accurata viti a ricircolo rendono il engrving più precisione. Anti-Flash nero, alta precisione, lungo il cerchio della vita. 4. software compatibilità: Type3/ArtCAMParameter Come usare: 1. assemblaggio e l'individuazione della macchina CNC in costante reception bene. 2. Assicurarsi che che il computer disponga di un'uscita di porta parallela 25pin. 3. Posizionare la casella di contral in luogo ventilato e asciutto dove non c'è nessuna polvere e umidità non 4. Collegare la casella di controllo con la macchina CNC e il computer e assicurarsi che la spina non staccarsi. 5. Collegare la macchina con il controller. Fare non sospeso il cavo che collega il motore mandrino con asse (X, Y, Z, A). In caso contrario, potrebbe danneggiare il driver del controller. 6 installare correttamente il motore mandrino e la pompa di calore. La pompa di calore dovrebbe essere coperto completamente l'acqua, poi acceso l'elettrico corrente per controllare se il sistema di raffreddamento funziona bene. 7 installare un CNC software di controllo e azionamento come il on il computer. 8 Fllowing nostro manuale o Guida di riferimento per impostare uo il software. 9 prima di accendere la macchina, si prega di controllare tutti i cavi e acquaraffreddamento di sistema per assicurarsi che si sta lavorando bene. 10 che si può godere facendo sognate con usando la nostra macchina CNC ora. Description: Do not need to install any software and driver, Spring can be stretched to 3 meters Waterproof design, very durable, anti-dirt, oil spray Power by parallel port Dimensions: 22 x 8 x 3cm The usb self-check light, you can type the " scroll" on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A- Feed rate control: F+, F- Jog rate: J+, J- Spindle speed: speed up, slow down Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point Package Include 1 * Remote controller 1 * Cable Applicable User&Skills 1. Advertising&Design staff 2. PCB Engineer 3. Woodwork fans 4. Model fans 5. User should better have electronics background 6. DIY ability to repair Highlights of water cooling system : It can cool the spindle and protect the machine Avoid the spindle burn out Can engrave the high hardness or metal It can improve the efficiency and accuracy of the machine. Payment Delivery details Return policy Feedback Con-tact us Payment We accept PayPal payment only Payment must be received within 7 days after order is made. Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Please pay attention to the payment in advance: according to experience, a transfer takes 2-3 days depending on the bank until the money is over. As soon as your payment is received, we will send you the goods within 48 hours. On Saturday and Sunday there is no delivery and no shipping. Please note: We ship parcels from Germany warehouse to europe buyers! 3-7 days: GERMANY 5-10days: Other countries We promise that every item has been sent. But sometimes there is also 0.3% package lost during transport . If this happens after we have confirmed this with the post, we will send you the package again as soon as possible or refund the money immediately. Return policy Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, Please tell us the problem in details and Please con-tact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as received . Customer is responsible for shipping costs of the returned item caused by misorder,or don't need it anymore. c) We will cover the cost of shipping if the item is defect when you received. Or We will send you a new unit or refund the full payment you paid. Feedback Thanks for buying my business. If you have any problem with the item, if you have got it, please do not hesitate to contact us. We will provide you the best solution for any problem with the item. We would be delighted if you kindly contacted us before requesting a return or leave negative feedback. Con-tact us Business Hour : Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply you-= within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please con-tact us with ebay message. Please feel free to con-tact us if you have any questions. Feedback On Jul-02-21 at 08:26:16 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Cooling	Water-cooling
MPN	Does not apply
Carving Instructions	G code / TAB files / nc file / NCC files
Country/Region of Manufacture	China
Communication interface	through parallel connection with computer
Model	6040
Software environment	Windows XP/Win7, 32bits system
UPC	Does not apply
Carving speed	0-2500mm/min(different materials differ
EAN	747180862560
Bundle Listing	Yes
X, Y, Z Working Area	600(Y)390X120(Z)mm
Control	CNC
Outside dimension	865680570mmLWH
Machine Type	3 Axis Router Machine
Table size	770Y*490Xmm
Power Source	Electric
Lathe structure	6061/6063 Aluminium alloy
Model Year	2020
Max. Feeding height	100mm
