1997 Mazak Quick Turn 20 W/ Mazatrol Tplus Control - Id# 104570

US $26,950.00

Dundee, Florida, United States
Jan 30th

Open on mobile:
QR code

1997 MAZAK QUICK TURN 20 MAZATROL TPLUS CONTROL ID# 104570 CAN BEEN SEEN UNDER POWER SPECIFICATIONS Chuck Size - 8" Hydraulic Chuck Maximum Swing Over Bed / Cross Slide - 17.32" / 10" Maximum Machining Diameter - 8.66" Distance Between Centers - 25.43" Maximum Bar Diameter - 2" X Axis Travel - 7.1" Z Axis Travel - 20.13" Spindle Nose / Bore - A2-6" / 2.44" Spindle Speed - 5,000 RPM Spindle Motor - 20 HP Rapid Traverse Rate - 1,300 IPM Number of Tools - 12 Position Turret Tailstock Stroke - 18.11" Machine Dimensions (L x W x H) - 105" x 69" x 74" Machine Weight (Approx.) - 9,400 Lbs EQUIPPED WITH 8" 3-Jaw Hydraulic Chuck Chip Conveyor Automatic Tool Eye Programmable Tailstock RS 232 Port Interface All Available Manuals DESCRIPTION The 1997 Mazak Quick Turn 20 is one of the most versatile members of Mazak's outstanding line of CNC Lathes. The combination of high-speed machine performance and CNC provides the fastest cutting time and minimized machine idle time. This sophisticated integration of machine and control provides exceptional productivity for medium to large size lots as well as small lot production. The CNC Mazatrol T-Plus incorporates one of the most advanced CPU's available. The processing speed is 4 times faster than that of the previous Mazatrol. In addition to the high performance CPU, the increased processing speed of the controllers and the smooth high gain servo system proves much faster machine motion with high accuracy. The new smooth high-gain servo control system minimizes shock at the start of servo motor rotation and deceleration to improve follow up accuracy. Machine vibration is minimized and an excellent finish surface is obtained even during high speed operation with frequent and sudden starts and stops and cutting sharp corners. Additionally, the high speed acceleration/deceleration ensures fast positioning and shorter cycle times. Thorough design consideration was given to thermal displacement of the spindle considerations such as symmetric headstock construction, thermally insulation the headstock from the machine base by special plates, and matching the thickness of these plates with the spindle center height to eliminate thermal displacement in the vertical direction. This minimum thermal displacement construction ensures high machining accuracy over extended period of continuous operation. To accommodate this cutting capability the machine is built with the sturdiest base available. Meehanite has superior shock absorbing characteristics and it can easily withstand the forces of heavy-duty machining. It also offers more stable long-term durability properties as well, this helps ensure consistent part accuracy throughout the life of the machine. The Mazak QT20 is unsurpassed in ease of operation. All controls and switches used in daily machine operation are located at the front of the machine. The pressure gauge, pressure adjustment knobs, lubrication oil gauge/inlet are all easily accessible. Tool setup is done by using the automatic Tool Eye System by simply bringing the tool tip into contact with the tool eye. The T-Plus control has a Tool Life Management System. By registering the maximum time a tool is to be used in the CNC Memory, the accumulated usage can be compared to this value during automatic operation. When a tool reaches its time limit, a spare tool will be automatically selected. An extremely fast Hi-Index coupling drum type turret provides tool indexing in only .35 seconds with a bidirectional tool selection, by the shortest path, minimizes non cutting time. Combine these features with the fast 1200/1300 inches per minute rapid traverse rates and you have the most productive small 2 axis turning center available.PAYMENTS ACCEPTED Paypal. For other payment options please contact Christina Ferguson at (863) 353 2693 or Toll Free at (855) 827 1387. We have the right to resell the item if it is not paid in full within (10) days. SHIPPING This machine is sold FOB "Buyer's Truck". All machines MUST ship on an Air-Ride Equipped Trailer (completely covered with tarps). We are more than happy to assist you in making arrangements to pick up your item. Please contact us for shipping & rigging quotes at (863) 353 2693 or Toll Free at (855) 827 1387. Shipping Dimensions Machine - 108" x 65" x 76" Chip Conveyor - 53" x 20" x 97" Chip Pan - 58" x 36" x 15" . STANDARD TERMS & CONDITIONS OF SALE 1. Unless otherwise stated in this agreement, the equipment is sold "AS IS, WHERE IS" with all faults and defects, known and unknown, whether obvious or latent. Seller expressly disclaims all warranties expressed or implied, including any warranty or merchantability or fitness for a particular purpose, or any warranty regarding the accuracy of equipment specifications or operability. 2. All descriptions of the equipment in this listing are approximate and for illustration only. Seller makes no representations or warranties that the equipment conforms to any such descriptions. It is the Buyer's responsibility to inspect the equipment and ascertain that the equipment conforms to the Buyer's requirements. 3. All sales are subject to applicable federal, state, and local use, sales and excise taxes which the Buyer agrees to pay, and which will be billed as part of the selling price, or separately, if the Seller is required by any taxing authority to collect and pay such a tax. 4. Buyer/User agrees to indemnify, hold harmless Seller, it subsidiaries, affiliates Salesperson(s) or any agents of and from any and all claims or liabilities involving, or alleged involve, these goods, which are caused by acts arising from the equipment of the efface hereof or omissions of the Buyer, his employees, assigns or agents. 5. Buyer acknowledges that the goods described herein are preowned used goods, which were neither designed nor manufactured by the Seller. Nor has the Seller knowledge of, or control over the future application of these goods by the Buyer. It is the Buyer's (User's) responsibility to provide proper safety devices and equipment for any particular use, operation, or setup, and take all necessary steps to conform to all federal, state and local government safety standards, including OSHA.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Make	Mazak
Swing Over Bed	17.32"
Model Year	1997
Distance Between Centers	21'' - 30''
Model	Quick Turn 20
Highest Spindle Speed (RPM)	4501 - 5000
Serial Number	131569
Hole Thru Spindle	2.44"
