1pcs 84x84 Lcd Module Backlight Adapter Pcb For Nokia 5110 Arduino Diy

US $3.56

  • Philippines, Philippines
  • May 9th
Open on mobile:
QR code
Description Description: 1.Parameters 1>.Power supply voltage:2.7V-3.3V 2>.Data interface level:2.7-3.3V 3>.Backlight power supply voltage:highest 3.3V 4>.Module size:43.6mm x 43.1mm(width X height) 5>.Installation diameter:2mm 2.Connection 1>.RST--------- reset 2>.CE---------- chip selection 3>.DC---------- data/commands choice 4>.DIN--------- serial data line 5>.CLK--------- serial Clock Speed 6>.3.3V-------- VCC 7>.LIGHT------- backlight control terminal 8>.GND--------- power negative 3.Features: 1>. 84 X 84 dot matrix LCD,can show 4 lines of characters 2>. Use serial interface communicate with the master processor,the number of interface signal line reduced greatly, only 8 signal lines including power and GND.Support different types of MCU,such as the arduino,AVR,PIC,STM32,STC MSP430 and so on.Transfer rate up to 4Mbps,can full speed write display data without waiting time. 3>. Can use the conductive glue to connect the module with the printed board,without connecting cable.The metal hooks on the module can fix the module on the printed board,which is very easy to install and replace. 4>. LCD controller/driver chip has been bound to LCD chip,the volume of LCD is small 5>. Low power supply,the working current in normal situation is lower than 200?A,and has power-down mode       Shipping •Item will be shipped within 24 hours after full payment is received. •Normally the shippment to worldwide is used to take 20 to 25 business days, exclude Sat & Sun   Payment •We accept PayPal only. •Payment must be received in 7 business days of auction closing. •Please leave note for your special request (e.g. Colors or Size) in ebay note when you pay the order. •Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched.   Content Us •If you have any questions, please feel free to email our servicer ,and we will reply you ASAP. If no response within 24 Hours, please check the spam of mail box or kindly re-send it to us. •We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact. If you haven't received item in 45 days, please contact us and we will arrange refund or resend
