2.2" 2.2in Spi Tft Lcd Module Display + Pcb Adapter 2.8-3.3v Lcd Board

US $7.20

shenzhen, China
Jun 9th

Open on mobile:
QR code

Product Name: NEW 2.2" 2.2in SPI TFT LCD Module Display + PCB adapter More Items In Our Store,Click Here! SKU: 3592 Parsts No. : Package: Brand: Quantity: 1 Description: - Size: 2.2 inch - Resolution:240 * 320 Instructions: Program default IO connections: sbit LCD_CS = P0 ^ 0; Chip Select sbit LCD_RS = P0 ^ 2; data / command switch sbit LCD_SDA = P1 ^ 5; Data sbit LCD_SCK = P1 ^ 7; Clock sbit LCD_REST = P0 ^ 1; Reset ? TFT Power: Screen Power is 2.8-3.3V; remember not to use 5V (Modules with PCB's have inherited 3V regulator IC, you can enter 5V) ? backlight power supply (LED pin): 3.2V maximum backlight power (At 3.3V supply can be connected in series for 10 ohm current limiting resistor in series with 100 ohms or 5V Resistance). ? Data port level: theoretically can not let the data port level exceeds 3.3V, if you must IO connection with 5V microcontroller data bus, as tft internal voltage clamp, with Can be used, but is not always standard. You can do an experiment to test a sample batch Made product, in order to improve product stability, better use of low-voltage monolithic Machine or add a level converter IC. Material Download Any problem, please contact us freely 1) We accept PayPal payment ONLY. On Mar-20-15 at 19:45:41 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Type	2.2" TFT LCD
MPN	Does not apply
Gender	Does not apply
Country/Region of Manufacture	China
Year	Does not apply
UPC	Does not apply
