DC-DC 7-32V 10A Buck Converter Adjustable 200W For Battery/LED/Car Power Module Description: Features: Module Properties: Non synchronous rectifier,non-isolated buck,constant current& voltage, CC CV charging mudule Input Voltage: 7-32V Output Voltage: 1.25V - 28V(adjustable) Output Current: 10A Max, 8A for long time working Output Power: 200W Working Temperature: -40°C to +85°C Working Frequency: 300 KHZ Tranfer Efficiency: Max 95% (Efficiency is related with input,output voltage,current and voltage difference .) Constant Current Range: 0.3 to 10A (adjustable) Turn Lamp Current: Constant current value*(0.1),turn lamp current connect with constant current value ,for example when the constant current is 3A, turn lamp current is set to constant current 0.1 time (0.1*3A=0.3A). When the constant current value is 2A, turm lamp current is set for constant current 0.1 time (0.1*2A=0.2A) This version is fixed to 0.1 time (+-10%), Direction for charing or full of Tranfer effciency: Max 95% ( Efficiency is related with input,output voltage ,current and voltage difference.) Working Frenquency:300KHZ Output Ripple: Ripple is about 50mV( No noise) 20M bandwidth (For reference only ) input 24V ,output 12V 5A test result. Working Temperature : Industrial grade(-40°C-+85°C)(Please pay attention to the power tube temperature and strengthen the heatsink system when operating ) No Lload Current: Typical 20mA ( 24V tranfer to 12V) Load Regulation Rate: ±1%(Constanct voltage) Voltage Regulation rate: ±1% The precision of constant current and temperature :Constant current value is less than 5% when the testing temperature from 25 degree up to 60 degree.(Constant current value is 5A) Dynamic response speed : 5% 200uS Adjustting direction of potentiometer : Clockwise (increase), anticlockwise(decrease) Indicator (lamp):Two colors,red is charging while green is full of Output short circuit protection : Yes ,constant current (Constant current value is set up presently) Input reverse connection protection: No Output anti-flow-backwards protection : No, you need to add diode for battery Connection: Terminal Direction for charging battery: Make sure the floating charge voltage ,charging current and input voltage of rechangeable battery you need Setting the constant voltage potentiometer,and put the output voltage on about 5V Monitor output short circuit current by 10A current of multimeter ,and adjusting output current to the expected charging current by constant current potentiometer Adjustting the output voltage to the floating charge voltage by constant voltage potentiometer Connecting with the battery and try to charge (Step 1.2.3.4 are for module input connected with power,while no load output disconnected with battery.) Direction for LED constant current driver: Make sure LED working current and max working voltage you need to drive Adjusting the constant voltage potentiometer and put output voltage on about 5V Mornitor output short circuit current by 10A current of multimeter,and adjusting output current to expected LED working current by constant current Adjust the constant voltage potentiometer to LED max working voltage by output voltage potentiometer Connecting with LED ,and try to drive (Step 1.2.3.4 for module input connected with power,while no load output disconnected with LED max working voltage.) Module Size: 56 * 65 * 22mm/2.2*2.55*0.86" Color is shown as pictures Package Contents 100% Brand New 1 xDC-DC 7-32V 10A Buck Converter Adjustable 200W For Battery/LED/Car Power Module We can also wholesale if you need a large quantity of item please contact us :) Shipping : We only accept your Paypal Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 1 business day by Air Mail when your payment is clear. Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-22 >25 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-30 >35 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend France Rate (item arrived) 1.5% 20.5% 45% 23% 10% Refund or Resend Germany Rate (item arrived) 5.5% 25% 35% 19% 15.5% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Spain Rate (item arrived) 1.5% 25% 50% 14% 9.5% Refund or Resend Payment : We accept PayPal only. All major credit cards are accepted through secure payment processor PayPal. Payment must be received within 7 days of auction closing. If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from me and will combine them for your review. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. Refund&Reship: If you are dissatisfied with our item or service, then please follow the good eBay practice to contact us by ebay message before leaving any feedback. We are committed to resolve all issues in a friendly and satisfactory manner. We always reply to ebay messages within 1-2 business days. If you do not get a response from us, then please check your ebay message. we only reply ebay message, no send email. Original and return shipping fee will not be refunded or reimbursed under all circumstances. You must agree and acknowledge this term if you bid for this item. Therefore, please do not complain about having to ship back at your own expense. Contact US:: If have any question, Please contact us by ebay message(no e-mail). Reply within 24hours. We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply to your emails as soon as possible, however, due to high volume of daily incoming emails and time zone difference, we may not be able to reply your emails immediately. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Oct-10-15 at 00:28:33 PDT, seller added the following information:
