4.2v 3.6v 4.35v 5a Lithium Battery/ Iron Phosphate 18650 Charging Board Es1879s

US $97

ShenZhen ,Guangdong, China
Jun 9th

Open on mobile:
QR code

4.2V 3.6V 4.35V 5A Lithium Battery/ Iron phosphate 18650 Charging Board ES1879S Description: Input voltage range supports 5-20V, works like a 1879 from the power supply constant current limiting OR, charging algorithm optimization significantly compared to 1879, the speed can be increased by 5% -30% range (1879 by output line loss effects may advance into semi charging current causes slow), the board built-in automatic polarity + anti-reflux, can not exceed 2A automatic polarity battery current, bypassing the automatic polarity connected directly behind the anti-reflux can not exceed 5A battery current, jumpers or light support By the touch button to switch the charging voltage and the LED indication for easy viewing and to reduce the 1879 error ended voltage setting possible. The figure above, VIN input supply is +, GND connected to the input power - input power must be constant or current limiting with power, or general power series limiting resistor 1879 can this also comes with a black line - regardless NTC positive and negative welding in two marked on the NTC pads, NTC as close to the battery and the black part with good thermal grease to the battery, NTC If you need to extend the lead in the 10CM please try to control it. R board labeled end of times corresponding to the supplied LED long legs welded. When the constant current charging status LED is breathing close to the cut-off time PWM current reduction for quick flashing LED goes out after ~ ~ full. LED light color changes as of the voltage setting change. About Setting Up Voltage: board jumpers nothing welding voltage of 4.2V ended, LED is green when charging, when the 3.6 mark two pads are shorted As voltage is 3.65V, LED color is red, when the flag After two pads are shorted 4.35 As voltage is 4.35V, LED color mixing red and green. As if you need to use the buttons to switch voltage, connect 3.6 and 4.35V voltage pad As all shorted together, after the two pads marked K micro switch can be ended with a button to switch the voltage on welding, 3.6-4.2-4.35 loop adjustment, the same color LED jumper. package : 1pc module We accept PayPalonly. We only ship item to your PayPal verified address. Payment must be received within 3 Daysfrom the date of purchase. Please leave note in PayPal when making the payment if you have any special request (colors/size). Orders will be processed instantly and dispatched in same day normally, so we do NOT accept any Email/Message note before or after you place orders. All the items will be dispatched within 1 business day by Hong Kong Airmail after the payment is clear. Items will arrive in 7-25 business days. The arrival time depends on some factors and different areas: Please choose some local sellers, if you cannot wait patiently in the shipping time we declared. Once you purchase, please DON’Tleave negative or neutral feedback if you haven’t received item in 30 days, because we have mentioned the shipping time repeatedly. Customs duty is obligation and liability of a citizen in your country, so buyer should be responsible for any tax and custom duty incurred. For example, Laser Pointer is unacceptable in some countries. Therefore, please double check your local customs policy carefully before purchase. Or, we will NOT be responsible for any failure delivery related destination customs issue. All the products we are selling include factory warranty, don’t cover items that have been abused, burned and damaged in any form. Please contact us via eBay Messageif you have NOT received item in 30 days, we will check it with post office, and then resend or refund any missing item. In the unlikely event that your product is faulty in anyway, you must contact us ASAP and then return it within 7 Days of receipt. The postage and packaging fee will NOTbe refunded. We will not be responsible for the delivery or insurance charges incurred in returning item back to us. If you return an item purchased from us, it must be back in Factory Condition. This includes packaging, inserts, manuals etc. Please allow up to 5 Working Days for us to process your returned item. If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a Week. We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box. We greatly appreciate your POSITIVE feedback. Please do NOTleave negative feedback without asking for help. Our aim is to provide Top Level Customer Service, normally so we will try our best to solve any problem. Please DON’T leave negative or neutral feedback if you haven’t received item in 30 days, because we have mentioned the shipping time repeatedly. On Oct-10-15 at 18:51:39 PDT, seller added the following information:
