23mm Sandvik 880-D2300C4-03 Coro Drill + CAPTO CLAMP TOOL BLOCK (P 31), US $84 – Picture 0
23mm Sandvik 880-D2300C4-03 Coro Drill + CAPTO CLAMP TOOL BLOCK (P 31), US $84 – Picture 0

23mm Sandvik 880-d2300c4-03 Coro Drill + Capto Clamp Tool Block (p 31)

US $84

  • Dallas, Texas, United States
  • Jun 9th
Open on mobile:
QR code
BRAND NEW Sandvik Coromant 880-D2300C4-03 Indexable Insert Drill + NEW SANDVIK COROMANT 435-810111-R28 CAPTO CLAMPING TOOL BLOCK Drill Specs: For more technical details go to:  http://www.sandvik.coromant.com/en-us/products/pages/productdetails.aspx?c=880-D2300C4-03 Technical Specs ItemIndexable Drill SeriesCoroDrill 880 Capto Diameter23mm Drilling Depth2.717" Ratio3mm x Dia. Number of Inserts Required2 Inscribed Circle04 Cutting DirectionRight Shank TypeCoromant Capto C4 Shank Length36.0mm ANSI Number880-D2300C4-03 DC cutting diameter 23 mm SSCM_C1 insert seat size code 04C SSCM_P1 insert seat size code 04P SSCN_C1 insert seat size code 04C SSCN_P1 insert seat size code 04P LU usable length 72.45 mm CZC connection size code C4 DCON connection diameter 40 mm LF functional length 107.55 mm OAL overall length 135 mm LB1 body length 72 mm PL point length 3.45 mm   KAPR tool cutting edge angle 88 deg CNSC coolant entry style code 1: axial concentric entry CP coolant pressure 10 bar WT weight of item 0.4 kg MIIDM_C1 master insert identification 880-040305H-C-GM MIIDM_P1 master insert identification 880-0403W05H-P-GM MIIDN_C1 master insert identification 880-040305H-C-GM MIIDN_P1 master insert identification 880-0403W05H-P-GM BD1 body diameter 23 mm ADJLX maximum adjustment limit 0.5 mm TSYC tool style code 880..Cx-03 ZEFF face effective cutt edge count 2 GAMO orthogonal rake angle 5 deg LAMS inclination angle 0 deg CUTINT_MASTERP1 part2 of cutting item interface identifiers COR: CoroDrill 880 -size 04-P (880-0403W05H-P-GM) ADINTMS adaptive interface machine direction Coromant Capto (segment&bolt) -size C4 FEEDDIRCODE feed direction code EFW ADJLN minimum adjustment limit 0 mm BMC body material code 1 CXSC coolant exit style code 3: axial inclined exit FDC flute design code SSK FHA flute helix angle 22 deg FHH flute helix hand R ITEMTYPE item type Tool Item LCF chip flute length 85.4 mm NOF flute count 2 RELEASEPACK release pack id 05.2 RPMX rotational speed maximum 21500 r/min TCHAL achievable hole tolerance lower 0 mm TCHAU achievable hole tolerance upper 0.25 mm ULDR usable length diameter ratio 3.15 Checkout My Other Items Save BIG with Combined Shipping Discounts!  TX Residents must pay 8.25% Sales Tax
