24v1000w High Power Brushless Motor Driver Governor Potentiometer Speed Regulat

US $33.00

Shenzhen, China
Jul 4th

Open on mobile:
QR code

Note: This drive is a DC three-phase brushless and Hallless control board, and the motor can work normally without Hall. BLDC high-power 1000W adopts 18 MOS tubes, wide voltage 6-24V, DC three-phase high-speed brushless and non-inductive controller, supports PLC 0-5V analog input control Interface Description: 1.U V W 3-phase DC output connected to brushless motor 2. VCC GND drives the main power supply (external DC power supply) 3. Forward and reverse active brake control (connect to the ground with a three-gear switch, keep the low level active) 4. Potentiometer stepless speed regulation (standard power distribution potentiometer speed regulation can also be external 0-4.5V analog signal input speed regulation) Full SMD technology, humanized design, standard control switch, speed potentiometer, no need to add control signal to the hand, it can be used when power is on, saving time and worry Motherboard specifications: Product name: ZS-X60 V1 Working voltage: 6-20V (limit 24V) Drive current: rated 30A plus air cooling 50A Maximum power: 1000W Overcurrent protection: Yes Locked-rotor protection: Yes (after locked-rotor, the current will automatically drop and run at intervals) Over-temperature protection: Yes (over-temperature power is halved) Maximum speed: 224000 RPM (2 pole motor), 74000 RPM (6 pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor). Product size: length 99MM* width 36MM* height 9MM Weight: about 67g Precautions: 1. Reverse connection of the positive and negative poles of the power supply on the motherboard will cause permanent damage to some of the chips on the board (large current will not work for a few seconds) 2. There is sampling over-current protection at the output of the motor during normal operation. Because the power and current of the module are very large, please do not artificially short-circuit the module when the module is not working normally. Once the short-circuit, the circuit may be burnt and the tube may burst. Please use small current and low voltage test, after ok, then apply high current and high voltage. Because it is a bare board module, please pay attention to the insulation of the wiring head. It is strictly forbidden that strong voltage touches the board parts. 3. Do not connect the motor that is obviously inconsistent with the voltage, current, or power of the drive module, or the motor is very different, to avoid inexplicable "nonsensical" damage

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Does not apply
Model Number	50A 1000W
MPN	Does not apply
Certification	FCC
Origin	CN(Origin)
Type	Does not apply
Motor Type	DC Motor
UPC	313109087033
ISBN	Does not apply
EAN	0313109087033
