2SB817 PNP Planar Power Transistor, US $3.18 – Picture 0

2SB817 PNP Planar Power Transistor, US $3.18 – Picture 1

2SB817 PNP Planar Power Transistor, US $3.18 – Picture 2

2sb817 Pnp Planar Power Transistor

US $3.18

The United Kingdom, United Kingdom
Jan 29th

Open on mobile:
QR code

2SB817 PNP Planar Power Transistor Click on an image to enlarge. 2SB817 PNP silicon planar transistor. This transistor is a power transistor commonly used in many models of audio amplifier output stages. It is commonly found in Rotel models but can be used in most domestic audio amplifiers as the PNP output device. This transistor the 2SB817 normally compliments the 2SD1047 NPN device. The transistor rating is as follows: Collector-Emitter Voltage, Vceo: 140V Collector-Base Voltage, Vcbo: 160V Emitter-Base Voltage, Vebo: 6.0V Collector Current Continuous/Peak, Ic/Icm: 12A/15A Power Dissipation @ 25 Centigrade: 100W Operating Temperature Range: -55 to 150 Centigrade Use Power Amplifiers Dimensions 16mm x 5mm x 18mm EAN 5060239762730 MPN 2SB817 Colour Black Material Semiconductor Manufacturer warranty 1 Year Product Weight 5g Model 2SB817 Brand Various Size 12A, 140V, 100W PNP

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Size	12A, 140V, 100W PNP
Dimensions	16mm x 5mm x 18mm
Colour	Black
Manufacturer warranty	1 Year
Brand	Various
Product Weight	5g
Material	Semiconductor
Use	Power Amplifiers
MPN	2SB817
EAN	5060239762730
Model	2SB817
