3-axes Cnc Machine Cnc3020 Cnc 3020 Router Engraver Drilling Milling Machine

US $664.05

default, default, Hong Kong
Jan 30th

Open on mobile:
QR code

3 Axis CNC Router 3020 with JY5300 Controller Box NEW Controller and Remote released in July 2013 ! The remote controller is an OPTIONAL purchase for only USD99. It does not included in this package by default. For more information, please send email to : cnc@mib-instruments.com Download Manual: Manual for CNC3020 V2 Machine Manual for JY5300-2 Controller Box and MHC2 Pendant NEW RELEASED FUNCTION AT SEP 2013: 1) USE Z shape arm (16mm Aluminium), can use the whole 300mm table and more reasonable on mechanical of the gravity weight of the motor. 2) BACK AL Panel enhance the strength 3) Front black plastic panel prevent dust and particle inside the screw part 4) Handwheel can connect with MACH3 by modbus 5) Can upgrade to 3D printer by just add a 3d extruder 6) Handwheel can command to set microstepping and current for each axis COMPARE OLD V1 AND NEW V2: 1) Enhanced Z shape arm, more room for Y axis 2) 15mm thickness Aluminum Alloy 6061 3) X Axis Front protection plate, avoid dust on the ballscrew 4) X Axis back metal plate 5) Z axis moving protection cover 6) Trimming screw nut, reduce the gap of the ballscrew 7) MHC2 pendant support MACH3, with 16 buttons, include autocheck, go to half new function NEW CONTROLLER JY5300 Features: 1) Support digital hand wheel controller MHC-2 2) Motion memory function. Can record the motion from Computer (e.g. Mach3), or hand wheel controller. Can play back the whole motion without computer controller. (Need MHC-1 Hand wheel controller) 3) Hand wheel controller with LCD display, can show X, Y, Z and A position up to 0.01mm 4) Hand wheel control motion smoothing function. Embedded acceleration and deceleration in hand controlling. 5) Can independently control up to 5 axis stepper motor (standard package is 4 axis) without Computer connected 6) Constant speed spindle motor function. Can detect spindle motor speed and provide more power automatically once the speed is dropped down. Fulfill low speed high power usage. 7) Spindle motor overcurrent protection, prevent motor board and motor damage 8) PWM spindle motor control with electronic acceleration and deceleration, extent the life of motor. 9) X, Y, Z axis Limit switches anti-crash function, once limit switch is triggered, the machine will automatically drive back 5 mm, prevent crash accident. 10) Independent control board. 1 pcs main board, 4 or 5 pcs stepper controller board and 1 pcs Spindle motor controller board. Easy to maintenance, repairing and replacement. 11) High velocity performance, velocity can drive up to 3500mm / minute, acceleration up to 400mm/s2 12) Extension function can connect to 800W or above water cooling type AC spindle Motor controller *Detail can consult sales MIB MINI CNC 3020 is suitable for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. MINI CNC 3020 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making, PCB, Adverstising Signs, Artwork, Crafts, Aircraft Models,RC Model parts,etc. Small size CNC can let you work in home or office.+ 1 Year Warranty for Mechanical Parts CNC Machine Specification: CNC Frame and MOTOR Specification Effective Traveling Range 200(X) X 300(Y) X90(Z) mm Machine Dimension 410(X)*540(Y)*440(Z) mm Working Table 240(X)*440(Y)*20(Z) mm Frame Material Aluminum Alloy 6061/ 6063 Driving Core X: 1605 ball screws Y: 1605 ball screws Z: 1605 ball screws Sliding Core X: Dia. 16mm Y: Dia. 16mm Z: Dia. 12mm Limit Switch X, Y, Z (2 switch per axis) Stepping Motor 57 2 phase 3A 1.8 Degree (Brand New) Spindle Motor Free upgrade to 300W NOW Brand New DC Motor - Torque: 230mN.m Voltage: 12 - 48 Volt DC. Speed: 2800 - 11500 RPM, Power: 180W Diameter: 51mm Jaw head len: 35mm Jaw head dia: 16mm Motor length: 135mm Principal Axis Collet ER11 / 3.175mm Spindle Speed PWM up to 13000 RPM Repeatability 0.05mm Max No Loading speed (X, Y, Z) 2500mm / min Spindle Precision (Beat error) 0.01 - 0.04mm Carving Code G code/TAB files/nc file/NCC files PC connection Parallel Port OS Win2000 XP (Support Mach2 Mach3) Carving Speed Depend on material Weight 28KG JY5300 Controller Specification Item Description Parameter Remark Socket Number of Slot Stepper Driver Board 5 *Standard package with 4 Stepper Driver Board DC Spindle Motor Driver Board 1 External Controller 1 PC Parallel Port 1 Stepper Motor Driver Board Operating Voltage 24DCV Maximum Current 3DCA Micro-Stepping divider 1:8 Hand Wheel Control Maximum Acceleration 200mm/s2 320 Steps per mm Maximum Deceleration 200mm/s2 Maximum Speed 3500mm/min MACH3 Computer Control Maximum Acceleration 300 mm/s2 Maximum Deceleration 300 mm/s2 Maximum Speed 3500mm/min Stepper Motion Memory Number of Memory Region 4 One Region Max Record Time 30minutes Maximum Memory Speed 3500mm/min DC Spindle Motor Driver Board Operating Voltage 48DCV Maximum Current 7DCA PWM Speed Control 0 to 100% 1KHz Constant Speed Tolerance 5 to 15% Tested in 300W 12000RPM DC Motor Maximum Acceleration ~3000RPM/s Maximum Deceleration ~3000RPM/s Input Electricity 110/220VAC 50/60Hz Hand Wheel LCD Display Dot Matrix 128X64 with backlight Hand Wheel Encoder 100 PPR Number of Axis 4 Axis Size Controller Box (LXWXH)mm 330X220X120 Weight net weight (kg) 4.3 First Installation in 30 minutes: 1. Locating the CNC machine on stable desk.2.Make sure that your computer has a on-board parallel port output. 3. Install control software and Drive such as the MACH 3 or EMC2 (You can search easy in Google) 4.Connect the X, Y, Z and Limit Switch socket from machine to CNC controller, connect power cord (We have already set the right voltage according your country). Connect parallel port from 5. Follow our instruction on the MACH3 setting. Package Include: 1) CNC and Controller Handwheel is not included, you can check below optional purchase Item Description Qty Tool Kit Pack 0.2mm V cut graver 1 0.3mm V cut graver 1 1mm drill 1 2mm flat milling graver 1 3.175mm flat milling graver 1 Mounting Clips 2 Spindle Motor opening tools 2 Carbon brush (Spindle Motor) 1 CNC Router Router Frame (Sliver) with Motors 1 Control Box JY5300-2 CNC controller box 1 Power Cord According to your country 1 Parallel Cable 1 Optional Purchase (Below optional Accessories are NOT INCLUDED), but you can purchase them with your order: 1) MHC-2 Hand Wheel Controller is USD99USD/ pcs New remote released in July2013, with more buttons, please refer to photos about. ********* The same price but more features ********* 2) Desktop Clamp additional cost is USD80 / pcs. 3) Tail - Stock, For additional USD100 only. 4) FREE OF CHARGE Upgrade Spindle motor to 300W YOU CAN UPGRADE TO 3D PRINTING You may be interested in converting your cnc to 3d printer too, we can provide the kits: Manual For CNC 3D printer kit: Manual for CNC To 3D Printer Manual for MC3D 3D Extruder Manual for M3D-H2 Heater Controller Manual for Heatbed FAQ: 1) Does the machine come with software? No, the package does not include software. This machine is compatible to Mach3 and EMC2 software, they are shareware and could be downloaded from their official website. So we do not ship with software. Hope you understand that. There are also a lot of Mach3 and EMC2 tutorials from the web. Please google them or check youtube for online tutorial. 2) Can this machine mill steel and how thick can it mill? Yes, it can mill steel but not very efficiently. User can set mill step for each run, say 0.2mm in the software to experience the effect. Milling steel is possible but may not be efficient with the default motor. We have a high power (water cool) motor with 800W power, 24000RPM. We can custom made for buyer for additional cost, please send email to us. 3) What is the power of the spindle motor? The spindle motor is 180W, it can be used to work on plastic, wood, aluminium and other soft materials. If you need more powerful spindle motor, please contact us by email : cnc@mib-instruments.com 4) How quick we ship the parcel after your purchase? After a buyer has paid for the CNC, the order will go to our factory. Before packaging, we will run 4 hours burn in test and then pack all accessories. The next day, we will send the parcel to our forwarder to get all the paperwork done. On the 4th day, we will have a shipper's reference number then the DHL waybill number will be published on the 5th day. Please understand that before the parcel is about 40Kg, so it take more time to prepare the shipment. 5) Warranty and After Sales Service (ASS) We provide 12 months warranty on functionality of all parts. We design and manufacturer the CNC machine, we keep close contact with all customers and collect their valuable feedback after sale. You are welcome send questions / comments to us anytime. We will try our best to solve any question regarding the CNC machine. Payment Shipping We accept Paypal, credit card through Paypal. Buyer may need to pay for import tax depend on your country's custom. You can ask us for more detail. We ship to most countries by DHL post. Since the parcel weight 35Kg, some countries do not allow parcel over 20Kg, so have to send by 2 parcels, we will send the aluminium flame and then the controller box. These counties include Russia, Brazil, CZ, Eastern Europe and Latin America. Items are shipped within 5 business day after receive payment. or we will send email to confirm shipment arrangement. An additional USD10 for insurance Most item will arrive within 8-14 business days. It depend on your location. In some case, ship to some countries will take over 3 weeks, especially brazil, Italy and France . eBay Cross Border Trade powered by Channel Effect On Aug-12-14 at 02:43:27 PDT, seller added the following information: Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MIB
Country of Manufacture	Hong Kong
Model	CNC3020
