300mw+ 650nm Red High Power Burn Laser Diode Module,diy Kit With Heat Sink

US $49.00

Seoul, default, Korea, South
Jan 30th

Open on mobile:
QR code

300mW+ 650nm Red Burning Laser Diode Module with Adjustable Lens 10 part precision Adjustable Constant Current about 100mA to 463mA routed PCB Test Driver DIY kit with protection circuit included. This item is for replacement of laser show red laser diode module. There are countless uses for a small compact Red laser, such as HOLOGRAPHY, LASER LIGHT SHOWS, Medical, etc... Please visit my store http://stores.ebay.com/Zet-Biz for other high power laser diode items. You are bidding on a precision new Single Mode Red 650nm long die open can laser diode module. Long die open can laser diodes are rated for Class IIIb 300mW+ @650-670nm CW extract from new(never used) DVD Bunner Driver. This long die open can diode have been probed to be very stable at high power output ranging from 300mW+. This is long die open can diode so they are extremly fragile therefore must very careful to open lens and must use proper heat sink for high power drive. The ideal use of this open can diode is 250mW CW at 420mA with acrylic lens( 300mW with glass lens). This module used acrylic lens but it is possible order optional glass lens at $12 for more power. Max Output : 300mW+ Max Current : 500mA Threshold Current : ~80mA Module : 12mm diameter x 30mm length Lead wire 30cm(Red plus[+], Black minus[-]) with 2.5mm pitch Connector. ALL : Assembled and inspected from licenced company. PCB and Parts can change without notice for improvement. Constant current driver kit include some safety circuit for laser diode protection- 9 part with Heat sink for LM317 and Laser Diode Module . Circuits included some filter, max current limit(about 463mW) for protect from over current, capacitor discharge and reverse current protection. Maximum current limit resistor can remove but I don't recommand because it's make easy kill your diode. I ship copy of driver schematic and layout for easy place parts. Input Voltage range from 6 V to 20V(eventhough IC can drive 37V but I limit it to 20V for safety) Place and soldering is very easy! By bidding you AGREE and ACCEPT: You Are over 18 and know the potential hazards inherent in high power laser equipment. You WILL use this device in a safe and sane manner for a legal purpose You Accept this item as a COMPONENT for integration in a system of YOUR OWN design and will hold the SELLER LEGALLY harmless from any and all LIABILITY You are buying A LOT QTY= 1 LASER DIODE MODULE FOR YOUR BID You know the electronic safety precautions necessary with this item and therefore accept it AS IT IS as an EXPERIMENTAL COMPONENT without warranty. Don't reply to email, some email not arrive and can erase with many spam mail. I sure Ebay message system is certain and leave evidence. $40 for FedEx international shipping about 2-5 days GLOBALLY. Standard shipping(Registered Mail) is $8, generally about 2 week, but rare case delay because destinations postal service. I combine ship and I accept paypal. Thanks for looking :-) For order glass lens, please "request total" from pay now window before pay. For See Laser Photo visite http://Zet.biz

Condition:

New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...

Product Type

Lasers
