3axis Nema 23 Stepper Motor 287oz-in & Driver Dm542a Cnc Kit Free Shipping

US $250.00

changzhou city,jiangsu province, China
Feb 13th

Open on mobile:
QR code

3AXIS Nema 23 Stepper Motor 287oz-in & Driver DM542A CNC Kit FREE SHIPPING Description Welcome to our website: http://www.longs-motor.com Email:cherry@longs-motor.com Skype:chenpeijuan2010 MSN:chenpeijuan2010@live.cn This item includes: 3 PCS Nema 23 stepper motor with 287 oz.in biopolar 3 PCS stepper motor driver DM542A, peak 4.2A, 128 micsteps, replacing M542 1 PC Power Supply 200Watts (24VDC/8.3A) 1pc breakout board +1 pc parallel cable Detailed information 1. Nema 23 stepper motor: Model Step angel (°) Motor Length L(mm) Rate Voltage (V) Rate Current (A) Phase Resistance (?) Phase Inductance (mH) Holding Torque (oz.in) Lead Wire (NO.) Rotor Inertia (g.cm2) Detent Torque (kg.cm) Motor Weight (kg) 23HS8610 1.8 78 8.6 1 8.6 18 287 6 480 0.68 1 2.Stepper motor driver: 1. Stepper motor driver--DM542A Features: High performance, low price Average current control, 2-phase sinusoidal output current drive Supply voltage from 18VDC to 50VDC Opto-isolated signal I/O Overvoltage, under voltage, overcorrect, phase short circuit protection 15 channels subdivision and automatic idle-current reduction 8 channels output phase current setting Offline command input terminal Motor torque is relased with speed, but not related with step/revolution High start speed High hording torque under high speed http://www.longs-motor.com/ProductsView.asp?id=267&pid=83 DM542A is a type of two-phase hybrid stepping motor driver, The drive voltage of which is from 18VDC to 50VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 42mm to 86mm outside diameter and less than 4.0A phase current. This circuit that it adopts is smiliar to the circuit of servo control which enables the motor run smoothly almost without noise and vibration. Hording torque when DM542A run under high speed is also significantly higher than the other two-phase driver, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, and computer embroider machine, packing machines and so on. 3. Power supply: The power of this power supply is 200Watts, and the output voltage/current is 24VDC/8.3A. 4. Breakout board: Description: • Built in DB25 male connector. • DB25 Output Pin:P1,P2,P3,P4,P5,P6,P7,P8,P9,P14,P16,P17. • DB25 Input Pin: P10,P11,P12,P13,P15. • DB25 GND Pin: P18-P25. • Power supply: +5V DC. • Built in C-class Optical-coupler. • High quality with Surface-mount Tech. Hello,thank you very much for your visit! If you want to buy more than 1set,please contact us,I will qoute you a completed price,thanks! Moreover,we are looking for distributors in the world,if you are intrrested in our programme,please contact us!Let's grow together!!!
