3axis Nema23 Dual Shaft Stepper Motor 112mm 425oz-in&driver&power Supply Cnc Kit

US $180.00

???, ???, China
Jan 29th

Open on mobile:
QR code

Package include: 3 x FMD2740A stepper motor driver 3 x 23HS2430B stepper motor (Dual shaft) 1 x 400W 36V/11A switching power supply 1 x 5 axis breakout board V5 type 1 x DB25 parallel cable 1 x USB cable English user manual for breakout board and stepper motor driver will send by email. 3 Axis for medium size Router Mill Plasma or Laser 1. 5 axis breakout board It can most connection 5pcs driver and control 5pcs motor in the same time It is with 4-wire limit switch to insure our safty movement It is with relay port to contro the cnc spindle Working voltage is 5VDC and support with MACH3,EMC2,KCAM4 software Size:9x5.7cm 2. FMD2740A stepper motor driver 1)Brief introduction FMD2740A FMD2740A driven by Japanese sanyo's chip,After multiple optimize R & D and production of high-subdivision 2-phase stepper motor drives, suitable for driving small and medium-sized phase current is less than 4A 2-phase or 4-phase hybrid stepping motor. Due to the adoption of the new bipolar constant current chopper drive technology, using the same motor can output more speed and power than other drivers. Segments stepper motor running accuracy improved, reduces vibrations and noise reduction. 2)Features 1. High-performance, low price 2. Bipolar constant current chopping mode 3. Power supply voltage 12 to 50VDC 4. High-speed optocoupler signal isolation input 5. 20kHz chopping frequency 6. Subdivision precision 2\8\16\32\64\128\10\20 optional 7. Electrical input signal is TTL compatible 8. Stationary current is automatically reduced by half 9. Shape design is convenient for installation 10.Maximum drive current is 4A 11.Drive any 4A phase current of 2-phase or 4-phase hybrid stepping motor 3)Applications Suitable for a variety of small and medium-sized automation equipment and instruments,for example: Small engraving machine, SMT machine, etc. 4)Wiring defined Weak signal interface Signal Function SP+ Pulse signal + end SP- Pulse signal - end DIR+ Direction signal +end DIR- Direction signal-end EN+ Enable signal +end EN- Enable signal -end Strengths connection port Signal Function VIN+ 12to50 v dc power supply input +end,it is recommended to use 36V3A GND DC power supply connection ground A+ Stepper motor A + Phase terminal A- Stepper motor A - Phase terminal B+ Stepper motor B+ Phase terminal B- Stepper motor B - Phase terminal NOTE: This drive does not contain anti-anti-interpolation circuit so non-input positive and negative power supply upside down! Otherwise it will damage the drive! 5)The electrical characteristics 6)The use of the environment and parameters Cooling method Natural cooling or forced air cooling Use of the environment Occasions Avoid dust, oil mist and corrosive gases Temperature 0°C-+50°C Humidity 40-90%RH Vibration 6m/s2 MAX Storage temperature -20°C-+65°C Weight 250g 7)Mechanical installation size 8) Power supply The supply voltage can work normally in between DC12V-50V, FMD2740A driver can use ordinary switch DC power supply, can also be used for transformer and the bridge rectifier and filter capacitor, capacitance desirable 2000U to 5000U. Note rectified voltage ripple crest does not exceed 50V.Recommended the user to use the 24V-32V DC supply , avoid the grid fluctuations over drive voltage operating range. Note: 1, Wiring should pay attention to the power of positive and negative Do not be reversed; 2, In order to reduce costs, multiple drives can share a power supply. But it should improve the rated power and rated output current of the power and attention to cooling. 9)Attenuation of the DIP switch settings Decay mode SW1 SW2 Slow decay OFF OFF Mixed decay ON OFF Fast decay OFF ON 10)Subdivision DIP switch settings 11)Current DIP switch settings 12)Drive motor controller wiring diagram 13)Electrical wiring The FMD2740A driver can drive all current 4A 4-wire, 6-wire or 8-wire 2-phase / 4-phase motors, are detailed below 4-wire, 6-wire, 8 wire stepper motor connection: 14)Matching of the drive and motor FMD2740A driver can drive the domestic and foreign manufacturers of 2-phase or 4-phase motor, in order to obtain the most satisfactory driving, you need to choose a reasonable supply voltage and current setting. Supply voltage determines the level of the high-speed performance of the motor, and the current set value determines the output torque of the motor. Supply voltage selected Generally speaking, the higher the supply voltage, the greater the torque motor at high speed, the more it can avoid the high speed out. But another aspect, the voltage is too high will lead to over-voltage protection, and can even damage the drive, but also in the high-pressure work, low speed vibrations. The output current is set For the same motor, the greater the current setting, the higher speed, the current motor and drive more heat. So under normal circumstances the current setting into a powered machine warm but not too hot long-term value. Note: the current settings after you run the motor for 15-30 minutes, if the motor temperature is too high, you should reduce the current settings. If the motor current setting, the motor output torque is not enough to improve heat dissipation conditions to ensure that the motor and drive are not hot. 3. Stepper Motor Technical Specifications Part No.: 23HS2430B Frame Size: NEMA23 Step Angle: 1.8 degree Current: 3.0A/phase Resistance: 1.6 Ohm/phase Inductance: 6.8 mH/phase Holding torque:280N.cm/28kg-cm 425 oz-in Rotor inertia: 800g-cm2 Number of wire leads: 4 Weight: 1.66 kg Length: 112mm General Specification: Step angle accuracy:+ - 5%(full step,not load) Resistance accuracy: + - 10% Inductance accuracy:+ - 20% Temperature rise: 80deg Max(rated current,2 phase on) Ambient temperature ----------—20deg ---- +50deg Insulation resistance:100ohm Min,500VDC Insultion Strength--------500VAC for one minute Datasheet(23HS2430,Front shaft 8mm dia and 21mm length,back shaft 8mm dia and 11mm length,425 oz-in or 28kg.cm holding torque) This product also has a single shaft for choice, the need to invite the message. Wiring: Red: A+ Green: A- Yellow: B+ Blue: B- 4.Switching power supply 400W,Input:100-120VAC or 200-240VAC,50/60Hz,Output:48v/8.3A,single output switching power supply 5.Usage or Application This products are widely used in engraving machine, printer, medical equipment, embroidery machine, stage lighting, textile automation, printing, packaging and other industries automation equipment. Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwidebut If your country’s custom is strict, please contact us before you bid to check detail and confirmed. Delievry time USA post service round 10-18 business days Canada China post round 25-40 business days Australia China post round 20-35 business days Western EU(Germany,UK,France, etc) China post 20-35 business days Asia,South America,other countries Chins post round 15-40 business days Note:above offer is default delivery way,if you need fast delivery like as DHL/UPS or post service pls inform us to confirm the shipping cost before you bid Above DHL/UPS offer is without remote fee,if your post code is remote it need extra cost. All items will be shipped within 1-3 business days upon receipt of payment Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos,after confirm we will refund your money,but the delivery charge paid by buyer. Contact us Email:sale1@rattmmotor.com,MSN:tonyswj@hotmail.com Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Phase	2
Model	23HS2430B/FMD2740A
Application 1	Semiconductor Equipment
MPN	http://hgauto.en.alibaba.com/
Application 2	Milling Machine, Engraver Machine
Country/Region of Manufacture	China
Application 3	CNC Routers
Holding Torque	425oz-in/ 280Ncm
Driver name	FMD2740A
Type	Hybrid
Driver Microstep	128 microstep
Current / Phase	3A
input voltage and current	12-50V,4A
Step Angle(degrees)	1.8
