3s 8a Li-ion Lithium Battery 18650 Charger Protection Board 10.8v 11.1v 12.6v

US $7.86

???, ???, China
Jan 29th

Open on mobile:
QR code

3S 8A Li-ion Lithium Battery 18650 Charger Protection Board 10.8v 11.1v 12.6V The protection plate using the Japanese Seiko lithium polymer rechargeable battery protection IC/ AO MOS tube; Characteristic. (1) for the high precision voltage detection function of each battery; (2) paragraph 3 overcurrent detection function; (3) the charge and discharge can control the battery through the MOS tube; (4) wide operating temperature range of:-40 DEG C ~ +85 ~ C; (5) with low current consumption. & use: · 3 string nickel cobalt manganese lithium, lithium cobalt oxide, manganese lithium-ion rechargeable battery pack; · 3 series lithium polymer rechargeable battery pack; Description: The serial number of the standard tests The 1 voltage charging voltage of DC:15V CC/CV Single balanced voltage of 4.2 V The 2 current single balanced current 42mA Single battery consumption (consumable) is less than or equal to 8uA Maximum continuous discharge current 8A 3 overcharge protection overcharge detection voltage 4.35V + 0.025 V Overcharge detection delay time 0.5S-1.5S Over charge recovery voltage of 4.15V + 0.05v 4 over discharge protection over discharge detection voltage 2.7V + 0.080 V Over discharge detection delay time 50-150ms Over discharge recovery voltage of 3.0V + 0.1V 5 overcurrent protection over current detection voltage 200 + 25mV Over current detection current 28 + 1A Over current detection delay time 5ms-15ms Restore state automatic recovery 6 short circuit protection status of external short circuit detection Detection delay time 200-500us Restore state automatic recovery 7 resistance protection circuit (MOSPET) is less than or equal to 10m. 8 working temperature range of +50 DEG C 40 ~ Storage temperature range of 40 ~ +125 C 9 dimensional (L*W*H) 50*21*2.8 MM & Weld Description: B+ is connected to the anode of the battery pack; Contact, B3 connected battery and the battery 1 2; Contact, B2 connect the battery and battery of 2 3; And B1 not connected; - B batteries cathode; P+ answer the charge / discharge end of the anode (charge / discharge end end share); P- answer the charge / discharge end (end of negative charge / discharge end share). wiring legend protection board: Package Included: 1 x 3S 8A Li-ion Lithium Battery 18650 Charger Protection Board 10.8v 11.1v 12.6V Dear buyers: Welcome to our store,Thanks! We try our best to provide you high quality and good service.Your satisfy is our aim. If you are satisfy with us,pleae leave five star positive feeback,and welcome to our store again,we will supply the good items and service all the time. If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve for you. Best Regards Shipping: We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Warranty and return: 12-months Warranty for defective items (excluding items damaged and/or misused after receipt). Refund or replacement request is available only the requests within 1 week after parcel received & returning the item as the same condition as received. Please contact us to request a return authorization. Your name, auction number, and reason for return should be included in the email. All items returned must contain all original packaging materials. Please repack the item carefully. Items returned will be tested and a new replacement will be shipped to the buyer immediately when found defective. In the event that a suitable replacement is not available then a refund will be issued. Shipping, handling and insurance fees are non refundable. Return shipping is to be paid by the Buyer. Contact us: We have much more products, if you need or have any question ,please contact us by leaving message or use Ali Trade manager .Welcome to wholesale. Thank you so much!
