4'' Stroke, 22lb Force, High Speed Linear Actuator, US $171.35 – Picture 0
4'' Stroke, 22lb Force, High Speed Linear Actuator, US $171.35 – Picture 0

4'' Stroke, 22lb Force, High Speed Linear Actuator

US $171.35

  • Swanton, Vermont, United States
  • Jul 15th
Open on mobile:
QR code
Description Stroke: 4'' Force: 22lb Input: 12Vdc 5A max current draw IP54 Rating Built-in limit switches This 4'' Stroke, 22lb, High Speed Linear Actuator is built from a tubular aluminum alloy. It features a light weight body, integrated with high speed planetary gear motor. It is suitable for any type of indoor/outdoor applications where high speed stroke is required and/or very low noise, measuring only 5dB above ambient. Specifications 9''/sec no load speed (230mm/sec) 4.5''/sec 22lbs load (120mm/sec) Duty cycle 20% Temperature range: -26ºC to +65ºC Wiring: 2 wires, reverse polarity changes direction Higher forces and slower speed options available for customer orders Uses MB8 brackets on both ends For power supply use manufacturer's power-adapters Closed length: 13.5" Open length: 17.5" Dimensions
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Firgelli Automations
Type Firgelli Automations
MPN FA-RA-22-12-4
UPC Does not apply
