4" Stroke, 25lb Thrust Linear Actuator, US $181.52 – Picture 0
4" Stroke, 25lb Thrust Linear Actuator, US $181.52 – Picture 0

4" Stroke, 25lb Thrust Linear Actuator

US $181.52

  • Swanton, Vermont, United States
  • Jul 15th
Open on mobile:
QR code
Description Operating Voltage: 6V - 12V Operating Temperature: -26°C ~ +65°C Speed (No Load): 2.00” per second Speed (Max Load): 1.37” per second Dynamic Thrust: 25 lbs Specifications   Product Weight: 40.2 oz Static Load: 500 lbs Current Drain (No-Load): 800mA Current Drain (Max Load): 3.8A Current Drain (Stall): 15A Motor Type: 3 Pole Ferrite Feedback Style: 10KΩ Potentiometer Potentiometer Tolerance: ± 5% Potentiometer Linearity: ± 0.25% Feedback Density: 2.5KΩ / inch Gear Ratio: 5:1 Gear Material: Metal Gear Train, Nylon Pinion Gearbox Style: Straight Cut Spur Wire Length: 24" Ingress Protection (IP): IP54 Duty Cycle: 25% (25% on, 75% off) Housing Material: Zinc Alloy Lead Screw Type: 3mm pitch, single thread Dimensions Multimedia
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand ServoCity
Type ServoCity
MPN HDA4-2
UPC Does not apply
