5 Axis 425oz &1090oz-in,5.6a Cnc 3d Stepper Spindle Motor Mill 85bygh450d-008

US $495.99

United States
Feb 26th

Open on mobile:
QR code

This item includes: 2 PCS Nema 34 Stepper Motor with 1090oz-in (7.7N.m) holding torque,5.6A current,99mm motor body length, 3 PCS Nema 23 Stepper Motor with 425oz-in holding torque Dual shaft, 2 PCS Stepper Drive with 7.8A DQ860MA replacing MD882, 3 PCS Stepper Driver with 4.2A DQ542MA digital serial replacing M542, 2 PCS Power Supply for 350W,60VDC,5.9A, 1 PC Power Supply for 350W,36VDC,9.8A, 1 PC DB25 Breakout Board, 1 PC Cable, 1, Stepper Motor 1, Technical Specifications Part No.: 85BYGH450D-008 Frame Size: NEMA34 Step Angle: 1.8 degree Voltage: 2.13V Current: 5.6A/phase Resistance: 0.38 Ohm/phase Inductance: 4.1 mH/phase Holding torque: 7.7N.m 1090oz-in Rotor inertia: 1700g-cm2 Number of wire leads: 4 Weight: 3 kg Length: 99mm Red A+ Green A- Yellow B+ Blue B- Note: Nema 34 Stepper Motor with 1090oz-in holding torque on single shaft, the diameter for motor shaft is 14mm. Both Single And dual shaft motors are available. If you need Double shaft, please tell us your requirements for length of front and rear shaft, as well as the diameter. So that we can offer you the quite good products, thanks! 2, Stepper Motor Driver DQ860MA Introduction,Features and Applications Introduction The DQ860MA is an economical microstepping driver based on patented technology of Wantai Motor .It is suitable for driving 2-phase 4-phase hybrid stepping motors .By using the advanced bipolar constant-current shopping technique ,it can output more speed and torque from the same motor,compared with traditional drivers ,such as L/R drivers .Its 3-state current control technology allows coil currents to be well controlled and with relatively small current ripple,therefore less motor heating is achieved. Features ?Low cost and good high-speed torque ?14 selectable resolutions ?Supply voltage up to +80VD ?Suitable for-2-phase and 4-phase motors ?Output current up to 7.8A, 5.86A rated current, 256 Microstep. ?Dip switch current setting 8different values ?Optically isolated input signals ?Pulse frequency up to 200KHz ?Automatic idle-current reductiOn ?Small size (107*97*48),Weight:0.3KG http://www.wantmotor.com 3, Stepper Motor Technical Specifications Part No.: WT57STH115-3004B Dual shaft Frame Size: NEMA23 Step Angle: 1.8 degree Voltage: 6.3VDC Current: 3 A/phase Resistance: 2.1Ohm/phase Inductance: 9mH/phase Holding torque: 30Kg-cm 425oz-in Rotor inertia: 810 g-cm2 Detent torque: 0.89 kg-cm Number of wire leads: 4 Weight: 1.55KG Length: 115mm The front shaft diameter is for 8mm, the rear shaft diameter is for 6.35mm, the front shaft length is for 21mm, the rear shaft length is for 15mm, round shafts! 4, Stepper Motor Driver with 4.2A Current, 128 Microstep DQ542MA is a type of two-phase hybrid stepping motor driver, The drive voltage of which is from 18VDC to 50VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 42mm to 86mm outside diameter and less than 4.0A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly almost without noise and vibration. Hording torque when DQ542MA run under high speed is also significantly higher than the other two-phase driver, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, Computer embroider machine, packing machines and so on. Features: l High performance, low price l Average current control, 2-phase sinusoidal output current drive l Supply voltage from 18VDC to 50VDC l Opto-isolated signal I/O l Overvoltage, under voltage, overcorrect, phase short circuit protection l 15 channels subdivision and automatic idle-current reduction l 8 channels output phase current setting l Offline command input terminal l Motor torque is related with speed, but not related with step/revolution l High start speed l High hording torque under high speed Electrical specification: Input voltage 18-50VDC Input current

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	wantai motor
MPN	www.wantmotor.com
Model	www.wantmotor.com
