5 Pcs A3967 V44 Easydriver Stepper Motor Driver Development Board For Arduino

US $8.99

Hong Kong, China
Mar 11th

Open on mobile:
QR code

5 Pcs A3967 V44 EasyDriver Stepper Motor Driver Development Board for Arduino *** Free Shipping WORLDWIDE *** Description: Stepper motor is usually defined with stepping angle or numbers of steps parameter, the general motor revolution is divided into 200 steps, which is the step angle of 1.8 degrees, EasyDriver has the function of interval subdivision, this driver board subdivision 8 segments, that is, each step of the motor is subdivided into 8 small step, this can be more precise control, that is to say, the EasyDriver needs to 1600 steps to complete a full 360 degree rotation. a3967slb PWM constant current control micro step distance driving for two phase stepper motor drives which is produced by allegro company in the United State. Its working voltage up to 30v, the drive current is 750ma, a a3967slb can drive a two-phase stepper motor drive and achieve 8 segments. The chip pwm current control circuit can be added to the pfd voltage and set to slow, fast and mixed three current-decay mode, if the voltage is higher than pfd end 0.6vdd, select slow decay mode. If less than 0.21vdd, then select the fast decay mode. Between the two decay modes is mixed mode. In addition, a3967slb also provide comprehensive protection measures, including transient voltage suppression, overheat protection against current through, under-voltage self-locking function. No additional other interface circuit between a3967slb and microprocessor, the chip taken easystepper interface, made 8 control lines reduce to 2 ( step and direction ), just need to simply enter the stepper motor control's pulse , its embedded converter can be achieved on the stepper motor control. A3967slb need some resistors, capacitors to adjust its operating parameters, the whole drive circuit is very simple. Features and Details: Ms1 and ms2 is the logic input port that selected by subdivide resolution of the stepper motor. Dir is the selects mouth of running direction of motor. Reset is used for reset the chip's original value, block all external output. Step is the pulse input port. Out1a, out1b, out2a, out2b is the h bridge's two pairs of output ports. Enable is enable end. sense1, sense2 is the h bridge's current sense resistor. Ref is the reference voltage. Qnd is logic and power. Rc1, rc2 is h bridge fixed deadline analog input. Package Included: 5 x EasyDriver stepper motor driver SHIPPING POLICY Shipment to Worldwide by Free Economy Shipping from China. Ships out my store within 1-3 business days after payment. With normal time, it takes about 20-30 business days for shipment arrival to your address by post office Since we use a free economy shipping option for all of our items, we do not provide tracking numbers. Estimated time of arrival is as follows: It will take 2-5 weeks to deliver an item to the USA and Asia; It will take 3-5 weeks to deliver an item to the United Kingdom, Australia and Canada; It will take 3-6 weeks to deliver an item to Europe; PAYMENT POLICY We accept paypal only. Once payment is received, your order will be processed and shipped (1-3 working days). Money Back Guarantee: Your 100% Satisfaction is Our #1 Goal. If you are not satisfied for any reason, please email us & return the item within 14 days. We will refund your purchase price without the shipping cost.

Condition:

New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...

Country/Region of Manufacture

China
