Uc-100 Usb Motion Controller

US $125.00

Lebanon, Illinois, United States
Mar 11th

Open on mobile:
QR code

USB MOTION CONTROLLER for MACH3 Windows 2000, Windows XP, Windows Vista, or Windows 7 Operating System will be ok Include: 1pcs UC-100, 1pcs USB cable, 1pcs Gender changer Features: - Very Easy to connect to the existing mach3 DB25 Breakout board or any new DB25 breakout Board. - Controls up to 6-axis simultaneously. - Works with Mach3 software via plugin. - Upto 100kHz operation. - USB connection from your PC to DB25 controller. - Same pinout as a standard LPT port. - Fast communication with data buffer for robust and stabile operation. - Comes with a DB25 gender changer, so it connects to Male or Female DB25 connectors. SPECIFICATIONS: - Automatic firmware checking and firmware update. - Motion control on upto 6-axis (X, Y, Z, A, B, C). - Configurable maximum stepping frequency, the options are 25kHz(with 20usec pulse length), 50kHz(with 10usec pulse length), 100kHz(with 5usec pulse length). - On the fly configurable 12 pieces of 5Volt (TTL level) buffered outputs. The current sink/source capability is 20mA max. per output. - On the fly configurable 5 pieces of 5V (TTL level) schmitt triggered and filtered inputs. The input internal pullup resistance to 5Volts is 4.7kOhms. - About 1 second long communication buffer. - 100% LPT port compatible pinout. FEATURES - Reference inputs. - E-stop input. - Softlimits. - Limit switch inputs. - Limits override. - Index input (extended function supports multi slot sensors). - Spindle speed PWM control output. - Step and direction spindle control output. - Spindle and coolant relay control. - Charge pump safety signal output (configurable to active/inactive when in E-stop). - Charge pump adjustable frequency (12.50kHz in normal or 5kHz in laser mode). - All signals configurable to active High/Low. - General purpose I/O signals handling. - Offline mode. - MPG1 and MPG2 support. - Slave axis. - Backlash compensation. - Digit/probe input. - THC control inputs. Product Manual& Downloads Userguider (3178) - Currently the automatic installer is working under the following operating systems: Windows XP Windows 7 32bit and 64bit versions. Windows 8 32bit and 64bit versions. Windows 8.1 32bit and 64bit versions

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country/Region of Manufacture

United States
